R-E-X-R-O-T-H AVENTICS 气缸 0822120003
- 型号：
- 0822120003
- 品牌：
- R-E-X-R-O-T-H轴承
- 系列：
- 内径d：
- mm
- 外径D：
- mm
- 厚度B：
- mm
R-E-X-R-O-T-H AVENTICS 气缸 0822120003参数
R-E-X-R-O-T-H AVENTICS 气缸 0822120003
| 品牌 | 0822120003 | 主要下游平台 | 亚马逊 |
|---|---|---|---|
| 主要销售地区 | 欧洲,南美 | 是否跨境出口专供货源 | 否 |
| 材质 | 0822120003 | 系列 | 0822120003 |
| 适用行业 | 轨道交通设备制造,通用设备制造,电子器件制造 | ||
包装信息
商品件重尺
| 规格 | 重量(g) |
|---|---|
| 0822120003 | 500 |
商品详情
Specifications
- Standards
- ISO 15552
- Piston Ø
- 32 mm
- Stroke
- 80 mm
- Functional principle
- Double-acting
- Cushioning
- Pneumatic adjustable cushioning
- Magnetic piston
- Piston with magnet
- Environmental requirements
- Industry standard, ATEX optional
- Piston rod
- single
- Scraper
- Standard Industry Scraper
- Pressure for determining piston forces
- 6,3 bar
- Retracting piston force
- 435 N
- Extracting piston force
- 505 N
- Min. ambient temperature
- -20 °C
- Max. ambient temperature
- 80 °C
- Working pressure min.
- 1.5 bar
- Working pressure max
- 10 bar
- Ports
- G 1/8
- Piston rod thread
- M10x1,25
- Cushioning length
- 16.5 mm
- Cushioning energy
- 4.8 J
- Weight 0 mm stroke
- 0.5 kg
- Weight +10 mm stroke
- 0.022 kg
- Stroke max.
- 1600 mm
- Medium
- Compressed air
- Min. medium temperature
- -20 °C
-
0821301512 Aventics R480070077 Aventics 0822010550 R480161377 0821301513 Aventics R480070078 Aventics 0822010551 R480161379 0821301514 Aventics R480070083 Aventics 0822010552 R480161388 0821301515 Aventics R480070120 Aventics 0822010553 R480161396 0821301516 Aventics R480070131 Aventics 0822010554 R480161408 0821301517 Aventics R480070141 Aventics 0822010555 R480161429 0821301520 OILER NL4 G3/8 Aventics R480070144 Aventics 0822010556 R480161477 0821301521 Aventics R480070148 Aventics 0822010557 R480161493 0821301522 Aventics R480070149 Aventics 0822010561 R480161544 0821301525 Aventics R480070151 Aventics 0822010562 R480161549 0821301540 Aventics R480070244 Aventics 0822010563 R480161586 0821301541 Aventics R480070245 Aventics 0822010564 R480161610 0821301542 Aventics R480070251 Aventics 0822010565 R480161617 0821301545 Aventics R480070263 Aventics 0822010566 R480161647 0821301702 Aventics R480070291 Aventics 0822010567 R480161652 0821301703 Aventics R480070295 Aventics 0822010570 R480161654 0821301704 OILER NL1 G1/4 PB Aventics R480070297 Aventics 0822010571 R480161656 0821301705 OILER NL1 G1/4 MB Aventics R480070303 Aventics 0822010572 R480161657 0821301801 Aventics R480070305 Aventics 0822010573 R480161665 0821301802 Aventics R480070325 Aventics 0822010574 R480161669 0821301803 Aventics R480070326 Aventics 0822010575 R480161675 0821301804 Aventics R480070356 Aventics 0822010576 R480161685 0821301805 Aventics R480070367 Aventics 0822010577 R480161688 0821301806 Aventics R480070377 Aventics 0822010600 R480161701 0821301808 Aventics R480070387 Aventics 0822010601 R480161702 0821302004 Aventics R480070388 Aventics 0822010602 R480161712 0821302005 Pressure Regulator Aventics R480070390 Aventics 0822010603 R480161714 0821302007 Aventics R480070392 Aventics 0822010604 R480161716 0821302010 Aventics R480070400 Aventics 0822010605 R480161717 0821302011 Aventics R480070402 Aventics 0822010606 R480161724 0821302025 Aventics R480070408 Aventics 0822010610 R480161733 0821302026 Aventics R480070416 Aventics 0822010611 R480161763 0821302031 Aventics R480070417 Aventics 0822010612 R480161771 0821302043 Aventics R480070437 Aventics 0822010613 R480161772 0821302044 Aventics R480070438 Aventics 0822010614 R480161797 0821302045 Pressure Relief Valve Aventics R480070439 Aventics 0822010615 R480161801 0821302046 RELIEF VALVE 0.1-2 BAR Aventics R480070454 Aventics 0822010616 R480161821 0821302047 Aventics R480070517 Aventics 0822010620 R480161829 0821302048 Aventics R480070522 Aventics 0822010621 R480161837 0821302050 Aventics R480070607 Aventics 0822010622 R480161844 0821302051 Aventics R480070614 Aventics 0822010623 R480161848 0821302052 Aventics R480070615 Aventics 0822010624 R480161862 0821302054 Aventics R480070629 Aventics 0822010625 R480606682 0821302055 Aventics R480070650 Aventics 0822010626 R480161901 0821302056 Aventics R480070657 Aventics 0822010627 R480161904 0821302057 Aventics R480070677 Aventics 0822010630 R480161908 0821302058 Aventics R480070683 Aventics 0822010631 R480161967 0821302059 Aventics R480070687 Aventics 0822010632 R480161994 0821302060 Aventics R480070689 Aventics 0822010633 R480143838 0821302061 Aventics R480070724 Aventics 0822010634 R480162073 0821302062 Pressure Regulator Aventics R480070726 Aventics 0822010635 R480162091 0821302063 Aventics R480070732 Aventics 0822010636 R480162105 0821302064 Aventics R480070733 Aventics 0822010637 R480162108 0821302065 Aventics R480070743 Aventics 0822010640 R480162146 0821302066 Aventics R480070746 Aventics 0822010641 R480162183 0821302067 Aventics R480070747 Aventics 0822010642 R480162207 0821302068 Aventics R480070749 Aventics 0822010643 R480162238 0821302069 Aventics R480070751 Aventics 0822010644 R480162301 0821302070 Aventics R480070784 Aventics 0822010645 R480162318 0821302071 Aventics R480070785 Aventics 0822010646 R480054506 0821302072 Aventics R480070787 Aventics 0822010647 R480162349 0821302073 Aventics R480070790 Aventics 0822010648 R480059919 0821302074 Aventics R480070792 Aventics 0822010649 R480162358 0821302075 Aventics R480070793 Aventics 0822010650 R480162365 0821302077 Aventics R480070795 Aventics 0822010651 R480162371 0821302078 Aventics R480070801 Aventics 0822010652 R480162377 0821302079 Aventics R480070802 Aventics 0822010653 R480162429 0821302080 Aventics R480070803 Aventics 0822010654 R480162449 0821302081 Aventics R480070804 Aventics 0822010655 R480162452 0821302082 Aventics R480070805 Aventics 0822010656 R480162461 0821302083 Pressure Regulator Aventics R480070807 Aventics 0822010657 R480162563 0821302084 Aventics R480070809 Aventics 0822010658 R480162586 0821302085 Aventics R480070810 Aventics 0822010659 R480162615 0821302086 Aventics R480070816 Aventics 0822010661 R480162632 0821302087 REGULATOR Aventics R480070817 Aventics 0822010662 R480601624 0821302088 Aventics R480070818 Aventics 0822010663 R480162684 0821302089 Aventics R480070819 Aventics 0822010664 R480162724 0821302090 Aventics R480070827 Aventics 0822010665 R480162725 0821302100 Aventics R480070830 Aventics 0822010666 R480162729 0821302106 Aventics R480070832 Aventics 0822010667 R480603160 0821302107 Aventics R480070833 Aventics 0822010668 R480162788 0821302108 Aventics R480070834 Aventics 0822010669 R480162798 0821302109 Aventics R480070839 Aventics 0822010671 R480162799 0821302143 Aventics R480070841 Aventics 0822010672 R480162835 0821302147 Aventics R480070842 Aventics 0822010673 R480162861 0821302148 Aventics R480070844 Aventics 0822010674 R480162877 0821302149 Aventics R480070846 Aventics 0822010675 R480162890 0821302150 Aventics R480070870 Aventics 0822010676 R480162900 0821302157 Aventics R480070873 Aventics 0822010677 R480162915 0821302160 Aventics R480070876 Aventics 0822010678 R480624592 0821302161 Aventics R480070877 Aventics 0822010679 R480607245 0821302162 Aventics R480070879 Aventics 0822010681 R480151871 0821302163 Aventics R480070894 Aventics 0822010684 R480162940 0821302165 Aventics R480070899 Aventics 0822010687 R480162941 0821302166 Aventics R480070900 Aventics 0822010688 R480162967 0821302167 Aventics R480070902 Aventics 0822010689 R480162975 0821302168 Aventics R480070914 Aventics 0822010691 R480162976 0821302169 Aventics R480070925 Aventics 0822010694 R480162983 0821302170 Aventics R480070927 Aventics 0822010697 R480162984 0821302171 Aventics R480070928 Aventics 0822010698 R480625539 0821302173 PR1-RGP-G012-GAN-070 G1/2 reg Aventics R480070935 Aventics 0822010699 R480165626 0821302178 Aventics R480070938 Aventics 0822010721 R480151816 0821302181 Aventics R480070944 Aventics 0822010722 R480162993 0821302183 Aventics R480070951 Aventics 0822010723 R480162995 0821302184 Aventics R480070970 Aventics 0822010724 R480162998 0821302187 Aventics R480070972 Aventics 0822010725 R480162999 0821302188 Aventics R480070974 Aventics 0822010726 R480057871 0821302190 Aventics R480070991 Aventics 0822010727 R480163015 0821302400 PRESSURE REGULATOR NL2 G1/4 Aventics R480070993 Aventics 0822010731 R480163016 0821302401 Pressure Reducing Valve Aventics R480070994 Aventics 0822010732 R480163017 0821302402 G1/4" NL2 Lockable reg+gauge Aventics R480070995 Aventics 0822010733 R480163018 0821302403 Aventics R480071005 Aventics 0822010734 R480163025 0821302404 Aventics R480071009 Aventics 0822010735 R480148020 0821302405 Aventics R480071032 Aventics 0822010736 R412013892 0821302406 Aventics R480071037 Aventics 0822010737 R480163046 0821302407 Aventics R480071038 Aventics 0822010741 R480163047 0821302408 Pressure regulator Aventics R480071040 Aventics 0822010742 R480601626 0821302409 Aventics R480071041 Aventics 0822010743 R480043125 0821302410 Aventics R480071063 Aventics 0822010744 R480604569 0821302411 G1/4 Regulator NL2 Aventics R480071064 Aventics 0822010745 R480602411 0821302415 Aventics R480071069 Aventics 0822010746 R480071957 0821302416 Aventics R480071076 Aventics 0822010747 R480163064 0821302417 Aventics R480071077 Aventics 0822010751 R480163084 0821302418 Aventics R480071079 Aventics 0822010752 R480163088 0821302419 Aventics R480071080 Aventics 0822010753 R480163097 0821302420 Aventics R480071100 Aventics 0822010754 R480163109 0821302421 Aventics R480071114 Aventics 0822010755 R480163115 0821302422 Aventics R480071116 Aventics 0822010756 R480163152 0821302423 Aventics R480071119 Aventics 0822010757 R480163153 0821302424 Aventics R480071124 Aventics 0822010761 R480163175 0821302425 Aventics R480071126 Aventics 0822010762 R480163204 0821302426 Aventics R480071132 Aventics 0822010763 R480163206 0821302427 PRESSURE REGULATOR 1/8" Aventics R480071140 Aventics 0822010764 R480163250 0821302428 Aventics R480071145 Aventics 0822010765 R480153475 0821302429 Aventics R480071171 Aventics 0822010766 R480163288 0821302430 Aventics R480071176 Aventics 0822010767 R480163298 0821302431 Aventics R480071179 Aventics 0822010771 R480163300 0821302432 Aventics R480071181 Aventics 0822010772 R480163304 0821302433 Aventics R480071188 Aventics 0822010773 R480163315 0821302434 Aventics R480071189 Aventics 0822010774 R480163316 0821302435 Aventics R480071190 Aventics 0822010775 R480163317 0821302436 Aventics R480071197 Aventics 0822010776 0822121027 0821302438 Aventics R480071213 Aventics 0822010777 R480163369 0821302439 Aventics R480071214 Aventics 0822010811 R480163475 0821302440 NL2 Reg 16 bar Aventics R480071219 Aventics 0822010812 R480163513 0821302441 Aventics R480071222 Aventics 0822010813 R480163534 0821302442 Aventics R480071235 Aventics 0822010814 R480163564 0821302443 Aventics R480071247 Aventics 0822010815 R480163572 0821302444 Aventics R480071249 Aventics 0822010816 R480163583 0821302445 PRECISION REG G1/4" 0.05-2BAR Aventics R480071257 Aventics 0822010817 R480163587 0821302446 PRECISION REG G1/4" 0.07-4BAR Aventics R480071259 Aventics 0822010821 R480163591 0821302447 PRECISION REG G1/4" 0.1-7BAR Aventics R480071262 Aventics 0822010822 R480163629 0821302448 Aventics R480071265 Aventics 0822010823 R480163693 0821302449 PRESSURE REGULATOR Aventics R480071267 Aventics 0822010824 R480163703 0821302451 Aventics R480071268 Aventics 0822010825 R480603137 0821302452 Aventics R480071271 Aventics 0822010826 R480163736 0821302453 Aventics R480071313 Aventics 0822010827 R480600530 0821302454 Aventics R480071314 Aventics 0822010831 R480163755 0821302455 Aventics R480071315 Aventics 0822010832 R480163757 0821302456 Aventics R480071316 Aventics 0822010833 R480163760 0821302457 Aventics R480071317 Aventics 0822010834 R480163790 0821302458 Aventics R480071324 Aventics 0822010835 R480163803 0821302459 Aventics R480071326 Aventics 0822010836 R480163814 0821302500 Pressure Regulator Aventics R480071329 Aventics 0822010837 R480163856 0821302501 PRESSURE REGULATOR 1/2" Aventics R480071352 Aventics 0822010841 R480163866 0821302502 Aventics R480071355 Aventics 0822010842 R480163867 0821302503 Aventics R480071362 Aventics 0822010843 R480044745 0821302504 Aventics R480071363 Aventics 0822010844 R480163896 0821302505 Aventics R480071365 Aventics 0822010845 R480163918 0821302506 Aventics R480071378 Aventics 0822010846 R480163936 0821302507 Aventics R480071379 Aventics 0822010847 R480163938 0821302508 Aventics R480071388 Aventics 0822010848 R480163939 0821302509 Aventics R480071391 Aventics 0822010849 R480163940 0821302511 Aventics R480071411 Aventics 0822010851 R480163941 0821302512 Aventics R480071424 Aventics 0822010852 R480163942 0821302513 Aventics R480071445 Aventics 0822010853 R480163943 0821302514 Aventics R480071448 Aventics 0822010854 R480163944 0821302515 Aventics R480071454 Aventics 0822010855 R480163945 0821302516 Aventics R480071455 Aventics 0822010856 R480163946 0821302517 1/4" PRECISION REGULATOR NL2 Aventics R480071457 Aventics 0822010857 R480163947 0821302519 Aventics R480071459 Aventics 0822010858 R480163948 0821302520 Aventics R480071460 Aventics 0822010859 R480163949 0821302521 Aventics R480071461 Aventics 0822010861 R480163950 0821302522 Aventics R480071462 Aventics 0822010862 R480163951 0821302523 Aventics R480071463 Aventics 0822010863 R480163952 0821302524 Aventics R480071464 Aventics 0822010864 R480163953 0821302525 Aventics R480071465 Aventics 0822010865 R480163954 0821302526 Aventics R480071492 Aventics 0822010866 R480163955 0821302527 Aventics R480071501 Aventics 0822010867 R480163956 0821302528 Aventics R480071502 Aventics 0822010868 R480163957 0821302529 Aventics R480071512 Aventics 0822010869 R480163958 0821302530 Aventics R480071517 Aventics 0822010871 R480163959 0821302531 Aventics R480071518 Aventics 0822010872 R480163960 0821302532 Aventics R480071535 Aventics 0822010873 R480163961 0821302533 Aventics R480071537 Aventics 0822010874 R480163962
R-E-X-R-O-T-H0822120003轴承我司目前有部分库存，您可致电我司咨询销售人员关于轴承0822120003的图纸、轴承0822120003价格或同型号其他品牌替换等资料！我司与R-E-X-R-O-T-H厂家常年批量订购0822120003，以保证0822120003轴承质量正宗，价格最优。订购原装R-E-X-R-O-T-H 0822120003轴承请拨打：0532-83735255、13061287818
