ZYS轴承H71909C/P4

ZYS轴承H71909C/P4

  • 型号：
  • H71909C/P4
  • 品牌：
  • ZYS轴承
  • 系列：
  • 精密轴承
  • 内径d：
  • 45 mm
  • 外径D：
  • 68 mm
  • 厚度B：
  • 12 mm
ZYS轴承H71909C/P4参数
品牌 ZYS,其他 型号 主轴轴承H71909C/P4 加工定制 是
是否标准件 标准件 样品或现货 现货 是否进口 进口
类型 钢球 用途 角接触球轴承 材质 碳钢
尺寸 主轴轴承H71909C/P4






轴研所ZYS精密轴承H71909C/P4


调节，成对安装，接触角 α = 15°，非接触，加严公差

 ZYS轴承H71909C-P4

ZYS轴承H71909C-P4 (2)

ZYS轴承H71909C-P4



主轴轴承 HSS71909-C-T-P4S, 调节，成对安装，接触角 α = 15°，两侧唇密封，非接触，加严公差
径向载荷单向轴向载荷双侧密封终生润滑，免维护脂润滑
主轴轴承 HSS71909-C-T-P4S, 调节，成对安装，接触角 α = 15°，两侧唇密封，非接触，加严公差
主轴轴承 HSS71909-C-T-P4S, 调节，成对安装，接触角 α = 15°，两侧唇密封，非接触，加严公差


d 45 mm

D 68 mm

B 12 mm


a 14 mm

Da H12 61 mm

da h12 51,5 mm

ra max 0,6 mm

rmin 0,6 mm


m 0,147 kg
  质量
Cr 9600 N
  基本额定动载荷，径向
C0r 6000 N
  基本额定静载荷，径向
nG Fett 28000 1/min
  脂润滑时的极限转速
Cur 610 N
  疲劳极限载荷，径向



Bearing Number
  Brand QTY Price Memo Date Inquiry
H7006C/HQ1P4DBA   ZYS 22     ask spindle bearing 2016-04-11
BS4090TN1/P4QBCB   ZYS 21     ask spindle bearing 2016-04-11
7015C/P4TBTA   ZYS 1     ask spindle bearing 2016-04-11
H7013C/HQ1P2DTA   ZYS 1     ask spindle bearing 2016-04-11
H7008C/HQ1P2DTA   ZYS 1     ask spindle bearing 2016-04-11
H7207C/P4DTA   ZYS 96     ask spindle bearing 2016-04-11
7208AC/P4TBTA   ZYS 1     ask spindle bearing 2016-04-11
B71909C-2RZ/P4QBCB   ZYS 1     ask spindle bearing 2016-04-11
B71909C-2RZ/P4QBCA   ZYS 1     ask spindle bearing 2016-04-11
760313TN1/P4TBTB   ZYS 46     ask spindle bearing 2016-04-11
71926AC/P4GA   ZYS 16     ask spindle bearing 2016-04-11
7226C/P4   ZYS 1     ask spindle bearing 2016-04-11
7013CP4AGA   ZYS 1     ask spindle bearing 2016-04-11
7012CP4AGA   ZYS 1     ask spindle bearing 2016-04-11
7012ACP4AGA   ZYS 1     ask spindle bearing 2016-04-11
7011ACP4ADGB   ZYS 1     ask spindle bearing 2016-04-11
V7016CHQ1P2TBTA   ZYS 1     ask spindle bearing 2016-04-11
V7015CP4AQBCG   ZYS 1     ask spindle bearing 2016-04-11
V7013ACP4ATBTA   ZYS 1     ask spindle bearing 2016-04-11
V7007C2RZP4AGA   ZYS 1     ask spindle bearing 2016-04-11
V7006C2RZP4AGA   ZYS 1     ask spindle bearing 2016-04-11
V7004C2RZP4AGA   ZYS 1     ask spindle bearing 2016-04-11
V7003C2RZP4AGA   ZYS 1     ask spindle bearing 2016-04-11
71911CP4AGA   ZYS 1     ask spindle bearing 2016-04-11
71908CP4AGB   ZYS 1     ask spindle bearing 2016-04-11
B7000C/P4   ZYS 1     ask spindle bearing 2016-04-11
71908CP4AGA   ZYS 1     ask spindle bearing 2016-04-11
71907ACP4ADGB   ZYS 1     ask spindle bearing 2016-04-11
71906ACP4ADGB   ZYS 1     ask spindle bearing 2016-04-11
71906ACP4ADGB   ZYS 1     ask spindle bearing 2016-04-11
Bearing Number
  Brand QTY Price Memo Date Inquiry
71905CP4AGB   ZYS 1     ask spindle bearing 2016-04-11
71905CP4AGA   ZYS 1     ask spindle bearing 2016-04-11
71905CP4ADGB   ZYS 1     ask spindle bearing 2016-04-11
71903CP4AGA   ZYS 1     ask spindle bearing 2016-04-11
71901CP4AGA   ZYS 1     ask spindle bearing 2016-04-11
71901ACP4AGA   ZYS 1     ask spindle bearing 2016-04-11
B7000C/HQ1P4   ZYS 123     ask spindle bearing 2016-04-11
71900ACP4AGA   ZYS 1     ask spindle bearing 2016-04-11
7018C/P4GB   ZYS 99     ask spindle bearing 2016-04-11
B7008C/HQ1-2RZP4ADB   ZYS 1     ask spindle bearing 2016-04-11
B7011C/HQ1-2RZP4QBCA   ZYS 1     ask spindle bearing 2016-04-11
7211CP4AGB   ZYS 1     ask spindle bearing 2016-04-11
7209CP4AGB   ZYS 1     ask spindle bearing 2016-04-11
7209ACP4ADGA   ZYS 1     ask spindle bearing 2016-04-11
7205CP4AGA   ZYS 1     ask spindle bearing 2016-04-11
7204CP4AGA   ZYS 1     ask spindle bearing 2016-04-11
7204ACP4AGA   ZYS 1     ask spindle bearing 2016-04-11
7202ACP4AGB   ZYS 1     ask spindle bearing 2016-04-11
7201CP4AGA   ZYS 1     ask spindle bearing 2016-04-11
7005CP4AGA   ZYS 1     ask spindle bearing 2016-04-11
7005ACP4ADGB   ZYS 1     ask spindle bearing 2016-04-11
7004CP4AGA   ZYS 1     ask spindle bearing 2016-04-11
7004ACP4AGA   ZYS 1     ask spindle bearing 2016-04-11
7000CP4ADGB   ZYS 1     ask spindle bearing 2016-04-11
7000ACP4AGA   ZYS 1     ask spindle bearing 2016-04-11
7001CP4AGA   ZYS 1     ask spindle bearing 2016-04-11
7002ACP4AGA   ZYS 1     ask spindle bearing 2016-04-11
7002CP4AGA   ZYS 1     ask spindle bearing 2016-04-11
7005CP4AGB   ZYS 1     ask spindle bearing 2016-04-11
7008CP4ADTA   ZYS 1     ask spindle bearing 2016-04-11
Bearing Number
  Brand QTY Price Memo Date Inquiry
7008ACP4AGA   ZYS 1     ask spindle bearing 2016-04-11
7009CP4ATBTA   ZYS 1     ask spindle bearing 2016-04-11
7010CP4AGA   ZYS 1     ask spindle bearing 2016-04-11
71824AC/P4   ZYS 1     ask spindle bearing 2016-04-11
7017C/P4QBCB   ZYS 1     ask spindle bearing 2016-04-11
71905C/P4DBB   ZYS 49     ask spindle bearing 2016-04-11
71907C/HQ1P4DBB   ZYS 1     ask spindle bearing 2016-04-11
H7008C/P4DTA   ZYS 52     ask spindle bearing 2016-04-11


ZYS精密轴承H71909C/P4轴承我司目前有部分库存，您可致电我司咨询销售人员关于轴承H71909C/P4的图纸、轴承H71909C/P4价格或同型号其他品牌替换等资料！我司与ZYS厂家常年批量订购H71909C/P4精密轴承，以保证H71909C/P4轴承质量正宗，价格最优。订购原装ZYS H71909C/P4轴承请拨打：0532-83735255、13061287818
热销轴承型号：上一篇：ZYS轴承7002AC/P4GA SKF 23132-2CS轴承 TIMKEN HM807046/HM807010-B轴承 NSK 6014N轴承 NSK HR32320J轴承 NSK 40BNR10XTDUELP4高转速 精密 SKF 22212CC/W33轴承 NACHI深沟球轴承51101G KOYO R18/17轴承 FAG推力角接触球轴承 7603040-TV 下一篇：MAHR衬套N501-100/112x90-MESSIN
ZYS轴承H71909C/P4轴承图纸
