SKF轴承 350981 C,青岛瑞精机电现货供应0532-83735255
|
1.推力圆锥滚子轴承 2.尺寸:150-1200 mm 3.材质:GCr15SiMn,G20Cr2Ni4 4.质量认证:ISO9001:2000 5.应用:车床主轴, |
|||
| 产品描述: | 单向推力圆锥滚子轴承 | ||
| 轴承型号: | T1421 | ||
| 尺寸参数: | (内径) 355.6mm | (外径) 533.4mm | (装配高) 101.6mm |
| 重量 | 85.4 kg | ||
| 轴承系列: | SKF350982C, FAG509654, 829764，T441 | ||
| 原材料： | 高碳铬轴承钢GCr15, GCr15SiMn | ||
| 精度等级: | P6 | ||
| 游隙: | C2, C0, C3, C4, C5. | ||
| 保持架: | 黄铜保持架 | ||
| 应用领域: | 车床，磨床，轧机，钻压机，水力发电机，塔吊，螺杆轴的主轴，汽车转向装置等。 | ||
| 推力圆锥滚子 (inch) | |||||
| BEARING # | INDUSTRY # | BORE | O.D. | HEIGHT | WIEGHT |
| d | D | T | KG | ||
| TT 411 | T411 | 4.0000 | 8.5000 | 1.8125 | 8.9 |
| TT 441 | T441 | 4.4000 | 8.8000 | 2.2000 | 11.4 |
| TT 451 | T451 | 4.5000 | 9.8750 | 2.1250 | 15.0 |
| TT 511 | T511 | 5.0000 | 10.5000 | 2.3125 | 17.8 |
| TT 511 A | T511A | 5.0625 | 10.5000 | 2.3125 | 17.8 |
| 0.0 | |||||
| TT 520 | T520 | 5.0000 | 9.8750 | 2.1875 | 13.9 |
| TT 611 | T611 | 6.0000 | 12.5000 | 2.7500 | 29.3 |
| TT 651 | T651 | 6.5000 | 12.2500 | 3.5000 | 38.3 |
| TT 661 | T661 | 6.6250 | 12.0000 | 2.7500 | 27.8 |
| TT 691 | T691 | 6.8750 | 14.1250 | 3.2500 | 45.3 |
| 0.0 | |||||
| TT 711 | T711 | 7.0000 | 14.5000 | 3.2500 | 48.4 |
| TT 811 | T811 | 8.0000 | 16.5000 | 3.6250 | 69.3 |
| TT 811 X | T811X | 8.0000 | 16.5000 | 4.7500 | 92.7 |
| TT 811 XA | T811XA | 8.0000 | 16.5000 | 4.1875 | 81.8 |
| TT 911 | T911 | 9.0000 | 19.0000 | 4.1250 | 105.0 |
| 0.0 | |||||
| TT 911 A | T911A | 9.2500 | 19.0000 | 4.1250 | 103.0 |
| TT 921 | T921 | 9.2500 | 21.5000 | 5.0000 | 171.0 |
| TT 1011 | T1011 | 10.0000 | 21.2500 | 4.6250 | 147.0 |
| TT 1115 | T1115 | 11.0000 | 19.5000 | 5.2500 | 125.0 |
| TT 1120 | T1120 | 11.0000 | 23.7500 | 5.3750 | 212.0 |
| 0.0 | |||||
| TT 1421 | T1421 | 14.0000 | 21.0000 | 4.0000 | 83.9 |
| TT 7519 | T7519 | 7.4803 | 14.0000 | 2.9220 | 35.9 |
| TT 9020 | T9020 | 9.0000 | 17.0000 | 3.4950 | 65.7 |
| TT 14520 | T14520 | 14.5000 | 23.7500 | 4.7500 | 144.0 |
| TT 16021 | T16021 | 16.0000 | 28.0000 | 5.7500 | 264.0 |
| 0.0 | |||||
| TT 16050 | T06050 | 16.0000 | 33.0000 | 7.0000 | 517.0 |
| TT 48000 | T48000 | 48.0000 | 60.0000 | 5.3750 | 596.0 |
