| 品牌 | NSK | 型号 | 200TAC20DPN7+LC7 | 旧型号 | 200TAC20DPN7+LC7 |
| 内径 | 200（mm） | 外径 | 310（mm） | 厚度 | 132（mm） |
| 重量 | 1（kg） | 保持架及其材料 | N黄铜实体 | 使用特性 | 高速 |
| 用途 | 机床主轴 | 滚动体列数 | 双列 | 滚道类型 | 凸度滚道 |
| 样品或现货 | 现货 | 轴承材质 | 高碳铬轴承钢（全淬透型)(GCr15) | 滚动体类型 | 球 |
| 角度 | S特殊角度设计 | 密封盖 | 无密封 | 滚动体 | 钢球 |
| 类型 | 角接触球轴承 | 是否提供加工定制 | 是 |
NSK机床专用轴承200TAC20DPN7+LC7
NSK机床专用轴承200TAC20DPN7+LC7轴承尺寸|轴承规格参数|轴承报价
内径：200mm
外径：310mm
宽度：132mm
型号：200TAC20DPN7+LC7
类型：推力角接触球轴承
品牌：日本NSK轴承
备注：推力角接触球轴承
30TAC20D+L 30TAC20DPN7+LC6 30TAC20DPN7+LC7
35TAC20D+L 35TAC20DPN7+LC6 35TAC20DPN7+LC7
40TAC20D+L 40TAC20DPN7+LC6 40TAC20DPN7+LC7
45TAC20D+L 45TAC20DPN7+LC6 45TAC20DPN7+LC7
50TAC20D+L 50TAC20DPN7+LC6 50TAC20DPN7+LC7
55TAC20D+L 55TAC20DPN7+LC6 55TAC20DPN7+LC7
60TAC20D+L 60TAC20DPN7+LC6 60TAC20DPN7+LC7
65TAC20D+L 65TAC20DPN7+LC6 65TAC20DPN7+LC7
70TAC20D+L 70TAC20DPN7+LC6 70TAC20DPN7+LC7
75TAC20D+L 75TAC20DPN7+LC6 75TAC20DPN7+LC7
80TAC20D+L 80TAC20DPN7+LC6 80TAC20DPN7+LC7
85TAC20D+L 85TAC20DPN7+LC6 85TAC20DPN7+LC7
90TAC20D+L 90TAC20DPN7+LC6 90TAC20DPN7+LC7
95TAC20D+L 95TAC20DPN7+LC6 95TAC20DPN7+LC7
100TAC20D+L 100TAC20DPN7+LC6 100TAC20DPN7+LC7
105TAC20D+L 105TAC20DPN7+LC6 105TAC20DPN7+LC7
110TAC20D+L 110TAC20DPN7+LC6 110TAC20DPN7+LC7
120TAC20D+L 120TAC20DPN7+LC6 120TAC20DPN7+LC7
130TAC20D+L 130TAC20DPN7+LC6 130TAC20DPN7+LC7
140TAC20D+L 140TAC20DPN7+LC6 140TAC20DPN7+LC7
150TAC29D+L 150TAC29DPN7+LC6 150TAC29DPN7+LC7
150TAC20D+L 150TAC20DPN7+LC6 150TAC20DPN7+LC7
160TAC29D+L 160TAC29DPN7+LC6 160TAC29DPN7+LC7
160TAC20D+L 160TAC20DPN7+LC6 160TAC20DPN7+LC7
170TAC29D+L 170TAC29DPN7+LC6 170TAC29DPN7+LC7
170TAC20D+L 170TAC20DPN7+LC6 170TAC20DPN7+LC7
180TAC29D+L 180TAC29DPN7+LC6 180TAC29DPN7+LC7
180TAC20D+L 180TAC20DPN7+LC6 180TAC20DPN7+LC7
190TAC29D+L 190TAC29DPN7+LC6 190TAC29DPN7+LC7
190TAC20D+L 190TAC20DPN7+LC6 190TAC20DPN7+LC7
200TAC29D+L 200TAC29DPN7+LC6 200TAC29DPN7+LC7
200TAC20D+L 200TAC20DPN7+LC6 200TAC20DPN7+LC7
220TAC29D+L 220TAC29DPN7+LC6 220TAC29DPN7+LC7
240TAC29D+L 240TAC29DPN7+LC6 240TAC29DPN7+LC7
260TAC29D+L 260TAC29DPN7+LC6 260TAC29DPN7+LC7
280TAC29D+L 280TAC29DPN7+LC6 280TAC29DPN7+LC7
30TAC20D+L 30TAC20DPN7+LC6 30TAC20DPN7+LC7
35TAC20D+L 35TAC20DPN7+LC6 35TAC20DPN7+LC7
40TAC20D+L 40TAC20DPN7+LC6 40TAC20DPN7+LC7
45TAC20D+L 45TAC20DPN7+LC6 45TAC20DPN7+LC7
50TAC20D+L 50TAC20DPN7+LC6 50TAC20DPN7+LC7
55TAC20D+L 55TAC20DPN7+LC6 55TAC20DPN7+LC7
60TAC20D+L 60TAC20DPN7+LC6 60TAC20DPN7+LC7
65TAC20D+L 65TAC20DPN7+LC6 65TAC20DPN7+LC7
70TAC20D+L 70TAC20DPN7+LC6 70TAC20DPN7+LC7
75TAC20D+L 75TAC20DPN7+LC6 75TAC20DPN7+LC7
80TAC20D+L 80TAC20DPN7+LC6 80TAC20DPN7+LC7
85TAC20D+L 85TAC20DPN7+LC6 85TAC20DPN7+LC7
90TAC20D+L 90TAC20DPN7+LC6 90TAC20DPN7+LC7
95TAC20D+L 95TAC20DPN7+LC6 95TAC20DPN7+LC7
100TAC20D+L 100TAC20DPN7+LC6 100TAC20DPN7+LC7
105TAC20D+L 105TAC20DPN7+LC6 105TAC20DPN7+LC7
110TAC20D+L 110TAC20DPN7+LC6 110TAC20DPN7+LC7
120TAC20D+L 120TAC20DPN7+LC6 120TAC20DPN7+LC7
130TAC20D+L 130TAC20DPN7+LC6 130TAC20DPN7+LC7
140TAC20D+L 140TAC20DPN7+LC6 140TAC20DPN7+LC7
150TAC29D+L 150TAC29DPN7+LC6 150TAC29DPN7+LC7
150TAC20D+L 150TAC20DPN7+LC6 150TAC20DPN7+LC7
160TAC29D+L 160TAC29DPN7+LC6 160TAC29DPN7+LC7
160TAC20D+L 160TAC20DPN7+LC6 160TAC20DPN7+LC7
170TAC29D+L 170TAC29DPN7+LC6 170TAC29DPN7+LC7
170TAC20D+L 170TAC20DPN7+LC6 170TAC20DPN7+LC7
180TAC29D+L 180TAC29DPN7+LC6 180TAC29DPN7+LC7
180TAC20D+L 180TAC20DPN7+LC6 180TAC20DPN7+LC7
190TAC29D+L 190TAC29DPN7+LC6 190TAC29DPN7+LC7
190TAC20D+L 190TAC20DPN7+LC6 190TAC20DPN7+LC7
200TAC29D+L 200TAC29DPN7+LC6 200TAC29DPN7+LC7
200TAC20D+L 200TAC20DPN7+LC6 200TAC20DPN7+LC7
220TAC29D+L 220TAC29DPN7+LC6 220TAC29DPN7+LC7
240TAC29D+L 240TAC29DPN7+LC6 240TAC29DPN7+LC7
260TAC29D+L 260TAC29DPN7+LC6 260TAC29DPN7+LC7
280TAC29D+L 280TAC29DPN7+LC6 280TAC29DPN7+LC7
型号注释：
TAC前面数字：轴承内径尺寸
TAC:角接触推力球轴承，60°接触角
20D,29D:尺寸符号
PN7：特殊精密准确度
+L:内圈间隔
C6：标准预紧力，脂润滑
C7：标准预压油润滑
