NSK机床丝杠支撑座轴承WBK20-11

NSK机床丝杠支撑座轴承WBK20-11

  • 型号:
  • WBK20-11
  • 品牌:
  • NSK轴承
  • 系列:
  • 机床丝杠支撑座轴承
  • 内径d:
  • 20 mm
  • 外径D:
  • 20 mm
  • 厚度B:
  • 20 mm
NSK机床丝杠支撑座轴承WBK20-11参数
品牌 NSK 型号 WBK20-11 旧型号 WBK20-11
内径 20(mm) 外径 20(mm) 厚度 20(mm)
重量 1(kg) 保持架及其材料 J钢板冲压 使用特性 高速
用途 机床丝杠 滚动体列数 单列 滚道类型 直线滚道
样品或现货 现货 轴承材质 高碳铬轴承钢(全淬透型)(GCr15) 滚动体类型
角度 15度 密封盖 无密封 滚动体 钢球
工作原理 滚动 WBK20-11 WBK20-11 类型 深沟球轴承




日本NSK机床丝杠支撑座轴承WBK20-11轴承实物拍照日本NSK机床丝杠支撑座轴承WBK20-11轴承实物拍照日本NSK机床丝杠支撑座轴承WBK20-11轴承实物拍照日本NSK机床丝杠支撑座轴承WBK20-11轴承实物拍照日本NSK机床丝杠支撑座轴承WBK20-11轴承实物拍照日本NSK机床丝杠支撑座轴承WBK20-11轴承实物拍照日本NSK机床丝杠支撑座轴承WBK20-11轴承实物拍照日本NSK机床丝杠支撑座轴承WBK20-11轴承实物拍照日本NSK机床丝杠支撑座轴承WBK20-11轴承实物拍照



 螺桿固定座 規格表

EK/EF BK/BF FK/FF AK/AF WBK
螺桿支撐座各廠牌型號對照表
BALLSCREW SUPPORT UNITS EQUIVALENT INTERCHANGEABLE FOR MAJOR MANUFACTURER
SYK & THK
BK10
BK12
BK15
BK17
BK20
BK25
BK30
BK35
BK40
BF10
BF12
BF15
BF17
BF20
BF25
BF30
BF35
BF40
SYK & THK KURODA NSK
EK05 - -
EK06 BUR-6 WBK06-01A
EK08 BUR-8 WBK08-01A
EK10 - -
EK12 - -
EK15 - -
EK20 - -
EF06 - -
EF08 BUK-6S WBK08S-01
EF10 - -
EF12 - -
EF15 - -
EF20 - -
SYK & THK KURODA NSK
AK10 BUK-10F WBK10-01A
AK12 BUK-12F WBK12-01A
AK15 BUK-15F WBK15-01A
AK17 - WBK17-01A
AK20 BUK-20F WBK20-01A
- BUK-25F WBK25-01A
AF10 BUK-8S WBK10S-01
AF12 BUK-10S WBK12S-01
AF15 BUK-15S WBK15S-01
AF17 - WBK17S-01
AF20 BUK-20S WBK20S-01
- BUK-25S WBK25S-01
SYK & THK KURODA NSK
FK05 - -
FK06 - WBK06-11
FK08 BUM-08 WBK08-11
FK10 BUM-10 WBK10-11
FK12 BUM-12 WBK12-11
FK15 BUM-15 WBK15-11
FK17 - -
FK20 BUM-20 WBK20-11
FK25 BUM-25 WBK25-11
FK30 - -
FF06 - -
FF10 - -
FF12 - -
FF15 - -
FF17 - -
FF20 - -
FF25 - -
FF30 - -
螺桿支撐座固定端軸向負荷參考表
REFERENCE OF AXIAL LOAD OF FIXED-SIDE TYPE SUPPORT UNITS
支撐座型號 軸承 靜負荷
(kgf)
軸向負荷
(kgf)
極限轉速
(RPM)
FK06 EK06
706 106 53 -
FK08 EK08
708 148 74 -
BK10 AK10
FK10 EK10
7000A 266 133 16800
BK12 AK12
FK12 EK12
7001A 305 153 15400
BK15 AK15
FK15 EK15
7002A 350 175 13300
BK17 FK17
7203A 610 305 11200
7203B 565 363 7700
BK20
7004A 670 335 10500
  AK20
FK20 EK20
7204A 845 423 9100
7204B 780 501 6650
BK25 FK25
7205A 1050 525 8400
7205B 960 617 5950
BK30 FK30
7206A 1510 755 7000
7206B 1380 887 4970
BK35
7207B 1870 1202 4200
BK40
7208B 2340 1504 3710
螺桿支撐座適用滾珠螺桿外徑
TYPE OF SUPPORT UNITS AND APPLICABLE BALL SCREW DIAMETERS
固定側支撐座
內徑 (mm)
固定側支撐座
適用型號
支撐側支撐座
內徑 (mm)
支撐側支撐座
適用型號
適用滾珠螺桿
外徑 (mm)
5 EK05 - - Ø6
FK05
6 EK06 6 EF06 Ø8
FK06 FF06
8 EK08 6 EF08 Ø10
FK08 FF08
10 EK10 8 EF10 Ø10, Ø12, Ø14
FK10 FF10
BK10 BF10
AK10 AF10
12 EK12 10 EF12 Ø14, Ø15, Ø16
FK12 FF12
BK12 BF12
AK12 AF12
15 EK15 15 EF15 Ø20
FK15 FF15
BK15 BF15
AK15 AF15
17 BK17 17 BF17 Ø20, Ø25
FK17 FF17
20 EK20 20 EF20 Ø25, Ø28
FK20 FF20
BK20 BF20
AK20 AF20
25 FK25 25 FF25 Ø32, Ø36
BK25 BF25
30 FK30 30 FF30 Ø40, Ø45
BK30 BF30
35 BK35 35 BF35 Ø45
40 BK40 40 BF40 Ø50


IMG_6905

IMG_6906

IMG_6907



p30913-152651[1]





支撐座型號軸承靜負荷
(kgf)軸向負荷
(kgf)極限轉速
(RPM)

FK06 EK06 706 106 53 -
FK08 EK08 708 148 74 -
BK10
FK10
AK100
EK10
7000A 266 133 16800
BK12
FK12
AK12
EK12
7001A 305 153 15400
BK15
FK15
AK155
EK15
7002A 350 175 13300
BK17 FK17 7203A 610 305 11200
7203B 565 363 7700
BK20   7004A 670 335 10500
  AK20 7204A 845 423 9100
FK20 EK20 7204B 780 501 6650
BK25 FK25 7205A 1050 525 8400
7205B 960 617 5950
BK30 FK30 7206A 1510 755 7000
7206B 1380 887 4970
BK35 7207B 1870 1202 4200
BK40 7208B 2340 1504 3710












螺桿支撐座適用滚珠丝杠外徑



支撐座型號軸承靜負荷
(kgf)軸向負荷
(kgf)極限轉速
(RPM)
FK06 EK06 706 106 53 -
FK08 EK08 708 148 74 -
BK10
FK10
AK100
EK10
7000A 266 133 16800
BK12
FK12
AK12
EK12
7001A 305 153 15400
BK15
FK15
AK155
EK15
7002A 350 175 13300
BK17 FK17 7203A 610 305 11200
7203B 565 363 7700
BK20   7004A 670 335 10500
  AK20 7204A 845 423 9100
FK20 EK20 7204B 780 501 6650
BK25 FK25 7205A 1050 525 8400
7205B 960 617 5950
BK30 FK30 7206A 1510 755 7000
7206B 1380 887 4970
BK35 7207B 1870 1202 4200
BK40 7208B 2340 1504 3710








螺桿固定座/廠牌型號對照表



SYK & THK
BK10
BK12
BK15
BK17
BK20
BK25
BK30
BK35
BK40
BF10
BF12
BF15
BF17
BF20
BF25
BF30
BF35
BF40
SYK & THKKURODANSK
EK05 - -
EK06 BUR-6 WBK06-01A
EK08 BUR-8 WBK08-01A
EK10 - -
EK12 - -
EK15 - -
EK20 - -
EF06 - -
EF08 BUK-6S WBK08S-01
EF10 - -
EF12 - -
EF15 - -
EF20 - -

SYK & THKKURODANSK
AK10 BUK-10F WBK10-01A
AK12 BUK-12F WBK12-01A
AK15 BUK-15F WBK15-01A
AK17 - WBK17-01A
AK20 BUK-20F WBK20-01A
- BUK-25F WBK25-01A
AF10 BUK-8S WBK10S-01
AF12 BUK-10S WBK12S-01
AF15 BUK-15S WBK15S-01
AF17 - WBK17S-01
AF20 BUK-20S WBK20S-01
- BUK-25S WBK25S-01
SYK & THKKURODANSK
FK05 - -
FK06 - WBK06-11
FK08 BUM-08 WBK08-11
FK10 BUM-10 WBK10-11
FK12 BUM-12 WBK12-11
FK15 BUM-15 WBK15-11
FK17 - -
FK20 BUM-20 WBK20-11
FK25 BUM-25 WBK25-11
FK30 - -
FF06 - -
FF10 - -
FF12 - -
FF15 - -
FF17 - -
FF20 - -
FF25 - -
FF30 - -




NSK机床丝杠支撑座轴承WBK20-11轴承我司目前有部分库存,您可致电我司咨询销售人员关于轴承WBK20-11的图纸、轴承WBK20-11价格或同型号其他品牌替换等资料!我司与NSK厂家常年批量订购WBK20-11机床丝杠支撑座轴承,以保证WBK20-11轴承质量正宗,价格最优。订购原装NSK WBK20-11轴承请拨打:0532-83735255、13061287818
