美国MCGILL轴承VI-275287轴承NSN编号3110000889337 RF-1910-6
美国MCGILL轴承VI-275287轴承NSN编号3110000889337 RF-1910-6








		d 50 mm  D 72 mm  B 12 mm    Da max 75 mm  Db min 74 mm  d1 60,5 mm  da min 53,2 mm  E 72,5 mm  ra max 1 mm  rmin 1 mm  s 2,8 mm    距离中心位置的轴向偏移   m 0,296 kg    质量 Cr 36000 N    基本额定动载荷，径向 C0r 41500 N    基本额定静载荷，径向 nG Fett 14000 1/min    脂润滑时的极限转速 nG Öl 16000 1/min    最少油润滑时的极限转速 Cur 6400 N    疲劳极限载荷，径向



3110-00-828-6463 (3110008286463) NSN Information

NSNFSCNIINItem NameINC

3110-00-828-6463

3110

008286463

Bearing, Ball, Annular

00014

3110-00-828-6463 Features

MRCParameterCharacteristics

ABMK	Overall Width	0.1562 inches nominal
ABXV	Bore Diameter	0.3125 inches nominal
ADZG	Lubrication Material	OIL
AEPR	Flange Outside Diameter	0.5470 inches nominal
AGFF	Flange Width	0.0310 inches nominal
AGVV	Outer Ring Outside Diameter	0.5000 inches nominal
AGYE	Surface Finish	Ground
AGYF	Retainer Fabrication Method	Pressed
AGZC	Load Direction	Radial
AGZD	Bore Shape	Straight
AGZH	Internal FIT-UP Designation	Standard
CTFZ	Standard Tolerance Designation	Abec NO.7
LMDC	Lubrication Material Document AND Classification	MIL-L-6085 mil spec single material response
MATT	Material	Steel corrosion resisting ball
MATT	Material	Steel corrosion resisting inner ring
MATT	Material	Steel corrosion resisting outer ring
MATT	Material	Steel retainer
STYL	Style Designator	Non-loading groove, non-separable

3110-00-828-6463 Manufacturing Part Numbers (SKUs)

MFG SKUCAGESTATUSISCRNVCRNCCSADCDACHCCRNAAC

11732779-2	19200	A	1	2	7		A		BF
11732779-2	40920	A	1	2	3		5		ZZ
11732779-2	50294	A	1	2	3		5		ZZ
275287	85374	A	1	1	C	AC	5		KE
S8516FC	40920	A	1	1	5		5		KZ
S8516FC7P25L02	40920	A	1	2	5		5		ZZ
S8516FRP25L02	40920	A	1	9	5		X		XX
SFR1810K2-6	83086	A	1	2	5		4		KZ
SFR1810K25	83086	A	1	9	5		X		XX
SSR1F-8516	50294	A	1	1	C	AC	E		KE
SSRIF851RA7P25L01	50294	A	1	2	5		5		ZZ

3110-00-828-6463 Manufacturer

MFG SKUCAGEManufacturerTypeStatusRole

275287	85374	B V R Technologies Co.	A	A
11732779-2	50294	New Hampshire Ball Bearings Inc.	A	A
SFR1810K2-6	83086	New Hampshire Ball Bearings Inc.	F	A
SFR1810K25	83086	New Hampshire Ball Bearings Inc.	F	A
SSR1F-8516	50294	New Hampshire Ball Bearings Inc.	A	A
SSRIF851RA7P25L01	50294	New Hampshire Ball Bearings Inc.	A	A
11732779-2	40920	Timken Aerospace & Super Precision	A	A
S8516FC	40920	Timken Aerospace & Super Precision	A	A
S8516FC7P25L02	40920	Timken Aerospace & Super Precision	A	A
S8516FRP25L02	40920	Timken Aerospace & Super Precision	A	A
11732779-2	19200	U S Army Armament Research	A	A

3110-00-828-6463 Replaces the Following Cancelled NSN

Cancelled NSNCancelled NIIN

3110-00-873-5554

008735554

3110-00-828-6463 FLIS Identification

PMICADPE CODECRITL CODEDEMIL CODEDEMIL INTGNIIN ASGMTESDHMICENACSCHEDULE_BINC

A

0

X

A

1

01-JAN-62

N

8482105028

00014

3110-00-828-6463 FLIS Management

MOEREC REP CODEMGMT CTLUSCPHRASE CODEPHRASE STATEMENT

DN		9B-----	N
DS	N	-------	I
DF	N	SF9---V	F
DA	Z	T2200X-	A

3110-00-828-6463 Demilitarization Codes & Management

DMLPMICHMICADPECCriticalityESDC

A

N

0

X

3110-00-828-6463 Miscellaneous Management

MOE (S_A)SOSAACQUPUISLCCIICRCMCCSVC

DA	SMS	Z	1	EA	0	U	Z	T2200X-	A
DA	SMS	Z	1	EA	0	U	Z	T2200X-	D
DA	SMS	Z	1	EA	0	U	Z	T2200X-	F
DA	SMS	Z	1	EA	0	U	Z	T2200X-	N
DF	SMS	Z	1	EA	0	U		SF9---V	A
DF	SMS	Z	1	EA	0	U		SF9---V	D
DF	SMS	Z	1	EA	0	U		SF9---V	F
DF	SMS	Z	1	EA	0	U		SF9---V	N
DN	SMS	Z	1	EA	0	U		9B-----	A
DN	SMS	Z	1	EA	0	U		9B-----	D
DN	SMS	Z	1	EA	0	U		9B-----	F
DN	SMS	Z	1	EA	0	U		9B-----	N
DS	SMS	Z	1	EA	0	U		-------	A
DS	SMS	Z	1	EA	0	U		-------	D
DS	SMS	Z	1	EA	0	U		-------	F
DS	SMS	Z	1	EA	0	U		-------	N

3110-00-828-6463 Component / End Item

WPN SYS IDWPN SYS SVCWEAPON SYSTEM

17	N	Aircraft, Hawkeye E-2C
18	N	Aircraft, Intruder A-6E
19	F	Aircraft, Eagle F-15
24	F	Aircraft, Thunderbolt Ii, A-10
39	N	Helicopter, sea King H-3
41	N	Helicopter, CH-53 D/E
44	N	Helicopter, Lamps Mark III, SH-60B
45	N	Aircraft, Prowler EA-6B
47	N	Helicopter, Cobra/Attack, AH-1J
48	N	Helicopter, Utility/Search and Recovery UH-1N
58	N	Aircraft, Hercules C-130F
59	N	Aircraft, Hercules KC-130
61	N	F4N Aircraft
63	N	Aircraft, Orion P-3
C4	N	Helicopter, H1 All Versions
ER	N	Helicopter, Carrier Based Asw, SH-60F
MA	N	Consolidated Avionics Accessories
VM	N	F4S Aircraft
YL	N	Helicopter, Seahawk, H-60

3110-00-828-6463 Management Control Air Force

FUNDBUDGETMMACPVC

SF

9

V

3110-00-828-6463 Management Control Army

MATCAT 1MATCAT 2MATCAT 3MATCAT 4 5ARC

T

2

2

00

X

3110-00-828-6463 Management Control Navy

COGSMICIRRCSMCC

9B
