光洋KOYO轴承6700-2RS内径10mm外径15mm厚度4mm |
|
| 光洋KOYO轴承6700-2RS内径10mm外径15mm厚度4mm |
| Mold No. (New) | Mold No.(Old) | d(mm) | D(mm) | Thickness B(mm) | Weight (kg) |
| 617/3 | 3 | 6 | 2 | 0.0019 | |
| 617/3-2Z | 3 | 6 | 2 | 0.0028 | |
| 617/4 | 4 | 7 | 2 | 0.0021 | |
| 617/4-2Z | 4 | 7 | 2 | 0.0029 | |
| 617/5 | 5 | 8 | 2 | 0.0024 | |
| 617/5-2Z | 5 | 8 | 2 | 0.0034 | |
| 617/6 | 6 | 10 | 2.5 | 0.0053 | |
| 617/6-2Z | 6 | 10 | 2.5 | 0.0066 | |
| 617/7 | 7 | 11 | 2.5 | 0.0059 | |
| 617/7-2Z | 7 | 11 | 2.5 | 0.0071 | |
| 617/8 | 8 | 12 | 2.5 | 0.0068 | |
| 617/8-2Z | 8 | 12 | 2.5 | 0.0095 | |
| 617/9 | 9 | 14 | 3 | 0.0012 | |
| 61700 | 10 | 15 | 3 | 0.0016 | |
| 61700-Z | 6700Z | 10 | 15 | 4 | 0.0016 |
| 61700-2Z | 6700ZZ | 10 | 15 | 4 | 0.0016 |
| 61700-2BS | 6700-2BS | 10 | 15 | 4 | 0.0016 |
| 61700-2TS | 10 | 15 | 4 | 0.0016 | |
| 61701 | 12 | 18 | 4 | 0.0018 | |
| 61701-2Z | 12 | 18 | 4 | 0.0019 | |
| 61701-2TS | 12 | 18 | 4 | 0.0019 | |
| 61701-2ZLH | 12 | 18 | 4 | 0.0021 | |
| 61702 | 15 | 21 | 4 | 0.0022 | |
| 61702-2ZLH | 15 | 21 | 4 | 0.0024 | |
| 61703 | 17 | 23 | 4 | 0.01 | |
| 61704 | 20 | 27 | 4 | 0.02 | |
| 61704-2ZL | 20 | 27 | 4 | 0.02 | |
| 61704-2ZLH | 20 | 27 | 4 | 0.022 | |
| 61705 | 25 | 32 | 4 | 0.28 | |
| 61706 | 30 | 37 | 4 | 0.32 | |
| 61707 | 35 | 44 | 5 | 0.33 | |
| 61708 | 40 | 50 | 6 | 0.34 | |
| 61709 | 45 | 55 | 6 | 0.37 | |
| 61710 | 50 | 62 | 6 | 0.38 | |
| 617/3.175X3 | 33K1 | 3.176 | 6.25 | 2.36 | 0.0001 |
| 617/3.175X3-1 | 83K2 | 3.176 | 6.25 | 2.36 | 0.0013 |
