| 品牌 | 瑞精 | 型号 | 免维护关节轴承JET14 | 加工定制 | 是 |
| 是否标准件 | 标准件 | 样品或现货 | 现货 | 是否进口 | 进口 |
| 类型 | 钢球 | 用途 | 关节轴承 | 材质 | 碳钢 |
| 尺寸 | 免维护关节轴承JET14 |
JMC免维护关节轴承JET14内径14mm外径29mm厚度19mm |
|
| JMC免维护关节轴承JET14内径14mm外径29mm厚度19mm |
|
JMC ID (mm) |
JMC Model |
Mass (g) |
a° |
(C0/kgf) |
|||||||
| d | D | B | B1 | d1 | Φ | r | |||||
| 5 | JET 5 | 7 | 5 | 13 | 6 | 8 | 7.7 | 11.1 | 0.5 | 13 | 400 |
| JETS 5 | 7 | 5 | 13 | 6 | 8 | 7.7 | 11.1 | 0.5 | 13 | 400 | |
| 6 | JET 6 | 10 | 6 | 16 | 6.75 | 9 | 8.9 | 12.7 | 0.5 | 13 | 510 |
| JETS 6 | 10 | 6 | 16 | 6.75 | 9 | 8.9 | 12.7 | 0.5 | 13 | 510 | |
| 8 | JET 8 | 16 | 8 | 19 | 9 | 12 | 10.3 | 15.8 | 0.5 | 13 | 860 |
| JETS 8 | 16 | 8 | 19 | 9 | 12 | 10.3 | 15.8 | 0.5 | 13 | 860 | |
| 10 | JET 10 | 31 | 10 | 22 | 10.5 | 14 | 12.9 | 19.0 | 0.5 | 13 | 1,200 |
| JETS 10 | 31 | 10 | 22 | 10.5 | 14 | 12.9 | 19.0 | 0.5 | 13 | 1,200 | |
| 12 | JET 12 | 65 | 12 | 26 | 12 | 16 | 15.4 | 22.2 | 0.5 | 13 | 1,600 |
| JETS 12 | 65 | 12 | 26 | 12 | 16 | 15.4 | 22.2 | 0.5 | 13 | 1,600 | |
| 14 | JET 14 | 90 | 14 | 29 | 13.5 | 19 | 16.8 | 25.4 | 0.5 | 15 | 2,060 |
| JETS 14 | 90 | 14 | 29 | 13.5 | 19 | 16.8 | 25.4 | 0.5 | 15 | 2,060 | |
| 16 | JET 16 | 100 | 16 | 32 | 15 | 21 | 19.3 | 28.5 | 0.5 | 15 | 2,570 |
| JETS 16 | 100 | 16 | 32 | 15 | 21 | 19.3 | 28.5 | 0.5 | 15 | 2,570 | |
| 18 | JET 18 | 125 | 18 | 35 | 16.5 | 23 | 21.8 | 31.7 | 0.5 | 15 | 3,140 |
| JETS 18 | 125 | 18 | 35 | 16.5 | 23 | 21.8 | 31.7 | 0.5 | 15 | 3,140 | |
| 20 | JET 20 | 180 | 20 | 40 | 18 | 25 | 24.3 | 34.9 | 0.5 | 15 | 3,770 |
| JETS 20 | 180 | 20 | 40 | 18 | 25 | 24.3 | 34.9 | 0.5 | 15 | 3,770 | |
