进口INA单向滚针轴承HF1216内径12mm外径18mm厚度16mm尺寸_参数_报价_价格

滚针轴承HF1216青岛瑞精机电现货供应

滚针轴承HF1216轴承尺寸|轴承规格参数|轴承报价

内径：12mm
外径：18mm
宽度：16mm
型号：德国轴承HF1216

类型：单向滚针轴承

品牌：

备注：滚针轴承

Part No.	Dimensions (Metric/Inch)			Approx.	Interchange
Part No.	D	F	B	Wgt. lbs
RC-1/8	0.2812	0.125	0.25	0.02	-	RC-02
RC-1/4	0.4375	0.25	0.5	0.035	HFZ 040708	RC-040708
RC-3/8	0.625	0.375	0.5	0.047	HFZ 061008	RC-061008
RC-1/2	0.75	0.5	0.5	0.06	HFZ 081208	RC-081208
RC-5/8	0.875	0.625	0.625	0.07	HFZ 101410	RC-101410
RC-3/4	1	0.75	0.625	0.085	HFZ 121610	RC-121610
RC-1	1.3125	1	0.625	0.095	HFZ 162110	RC-162110
FC-3	6.5	3	6	0.01	HF-0306 KF	-
FC-4	8	4	6	0.01	HF-0406 KF	FC-4-K
FC-6	10	6	12	0.01	HF-0612	FCS-6
FCL-8	12	8	12	0.01	HF-0812	FCL-8-K
FC-8	14	8	12	0.01	-	FC-8
FCL-10	14	10	12	0.01	HF-1012	FCL-10-K
FC-10	16	10	12	0.01	-	FC-10
FC-12	18	12	16	0.02	HF-1216	FC-12
FC-14	20	14	16	0.02	HF-1416	-
FC-16	22	16	16	0.03	HF-1616	FC-16
FC-18	24	18	16	0.04	HF-1816	-
FC-20	26	20	16	0.04	HF-2016	FC-20
FC-25	32	25	20	0.07	HF-2520	FC-25
FC-30	37	30	20	0.08	HF-3020	FC-30
FC-35	42	35	20	0.09	HF-3520	FCS-35
