滚针轴承NX25-Z内径25mm外径37mm厚度30mm青岛瑞精机电现货供应0532-83735255
内径：25mm
外径：37mm
宽度：30mm
型号：滚针轴承NX25-Z内径25mm外径37mm厚度30mm
类型： 滚针轴承NX25-Z内径25mm外径37mm厚度30mm
品牌：滚针轴承NX25-Z内径25mm外径37mm厚度30mm
备注：滚针轴承NX25-Z内径25mm外径37mm厚度30mm
| Designation | Dimensions(mm) | Load Rating (kN) | Limiting Speed | |||||||||
| Open | With Shield | Fw | D | C | C1 | dw | rs | Radial | Axial | |||
| ± 0.25 | min. | Cr | Cor | Cr | Cor | rpm | ||||||
| NX7-TN | NX7-Z- TN | 7 | 14 | 18 | 4.7 | 7 | 0.3 | 2.85 | 2.65 | 3.15 | 4.3 | 15000 |
| NX10 | NX10-Z | 10 | 19 | 18 | 4.7 | 10 | 0.3 | 4.45 | 3.7 | 4.6 | 7.2 | 11000 |
| NX12 | NX12-Z | 12 | 21 | 18 | 4.7 | 12 | 0.3 | 4.8 | 4.3 | 4.85 | 8.2 | 9500 |
| NX15 | NX15-Z | 15 | 24 | 28 | 8 | 15 | 0.3 | 10.7 | 12.7 | 5.6 | 10.4 | 8000 |
| NX17 | NX17-Z | 17 | 26 | 28 | 8 | 17 | 0.3 | 11.9 | 15 | 5.8 | 11.5 | 7500 |
| NX20 | NX20-Z | 20 | 30 | 28 | 8 | 20 | 0.3 | 13 | 17.5 | 7 | 14.7 | 6500 |
| NX25 | NX25-Z | 25 | 37 | 30 | 8 | 25 | 0.3 | 14.9 | 22.4 | 11.1 | 24.3 | 4900 |
| NX30 | NX30-Z | 30 | 42 | 30 | 10 | 30 | 0.3 | 22.6 | 36 | 11.7 | 28 | 4300 |
| NX35 | NX35-Z | 35 | 47 | 30 | 10 | 35 | 0.3 | 24.3 | 41.5 | 12.4 | 32.5 |
3700 |
