INA轴承KB12-PP-AS

INA轴承KB12-PP-AS

  • 型号：
  • KB12-PP-AS
  • 品牌：
  • INA轴承
  • 系列：
  • 直线轴承
  • 内径d：
  • 12 mm
  • 外径D：
  • 22 mm
  • 厚度B：
  • 32 mm
INA轴承KB12-PP-AS参数
品牌 FAG 型号 直线球轴承 KB12-PP-AS 加工定制 是
是否标准件 标准件 样品或现货 现货 是否进口 进口
类型 钢球 用途 直线运动轴承 材质 碳钢
尺寸 直线球轴承 KB1232PPAS






进口轴承KB12-PP-AS直线球轴承KB1232-PP-AS


所有面进行密封，带再润滑设施；可提供耐腐蚀设计

 INA直线轴承KB12-PP-AS-KB1232

INA直线轴承KB12-PP-AS-KB1232 (4)

INA直线轴承KB12-PP-AS-KB1232 (3)

INA直线轴承KB12-PP-AS-KB1232 (2)



组件
直线球轴承 KB12-PP-AS, 所有面进行密封，带再润滑设施；可提供耐腐蚀设计
压缩载荷拉伸载荷全部密封脂润滑油润滑
直线球轴承 KB12-PP-AS, 所有面进行密封，带再润滑设施；可提供耐腐蚀设计


Fw 12 mm
  公差: +0,008 / 0
D 22 mm
  公差:h5
L 32 mm
  公差:h12

  5
  球的列数
BL2 1,3 mm
  根据 DIN 471，与锁圈匹配的槽的尺寸。
DN 21 mm
  根据 DIN 471，与锁圈匹配的槽的尺寸。
L2 22,6 mm
  公差:H13
N2 1,5 mm



  带初始油脂，两侧密封，带再润滑结构。
m 0,04 kg
  轴承的质量
Cmin 540 N
  基本额定载荷仅适用于淬硬（670+170 HV）及磨削过的作为滚道的轴。
C0 min 385 N
  基本额定载荷仅适用于淬硬（670+170 HV）及磨削过的作为滚道的轴。
Cmax 640 N
  基本额定载荷仅适用于淬硬（670+170 HV）及磨削过的作为滚道的轴。
C0 max 570 N
  基本额定载荷仅适用于淬硬（670+170 HV）及磨削过的作为滚道的轴。

 KB 1232 KB12 KB1232 KB12 KB 1232 PP KB12-PP KB1232-PP KB12-PP KB 1232 PP AS KB12-PP-AS KB1232-PP-AS KB12-PP-AS KB 1636 KB16 KB1636 KB16 KB 1636 PP KB16-PP KB1636-PP KB16-PP KB 1636 PP AS KB16-PP-AS KB1636-PP-AS KB16-PP-AS KB 2045 KB20 KB2045 KB20 KB 2045 PP KB20-PP KB2045-PP KB20-PP KB 2045 PP AS KB20-PP-AS KB2045-PP-AS KB20-PP-AS KB 2558 KB25 KB2558 KB25 KB 2558 PP KB25-PP KB2558-PP KB25-PP KB 2558 PP AS KB25-PP-AS KB2558-PP-AS KB25-PP-AS KB 3068 KB30 KB3068 KB30 KB 3068 PP KB30-PP KB3068-PP KB30-PP KB 3068 PP AS KB30-PP-AS KB3068-PP-AS KB30-PP-AS KB 4080 KB40 KB4080 KB40 KB 4080 PP KB40-PP KB4080-PP KB40-PP KB 4080 PP AS KB40-PP-AS KB4080-PP-AS KB40-PP-AS KB 50100 KB50 KB50100 KB50 KB 50100 PP KB50-PP KB50100-PP KB50-PP KB 50100 PP AS KB50-PP-AS KB50100-PP-AS KB50-PP-AS KBO 1232 KBO12 KBO1232 KBO12 KBO 1232 PP KBO12-PP KBO1232-PP KBO12-PP KBO 1232 PP AS KBO12-PP-AS KBO1232-PP-AS KBO12-PP-AS KBO 1636 KBO16 KBO1636 KBO16 KBO 1636 PP KBO16-PP KBO1636-PP KBO16-PP KBO 1636 PP AS KBO16-PP-AS KBO1636-PP-AS KBO16-PP-AS KBO 2045 KBO20 KBO2045 KBO20 KBO 2045 PP KBO20-PP KBO2045-PP KBO20-PP KBO 2045 PP AS KBO20-PP-AS KBO2045-PP-AS KBO20-PP-AS KBO 2558 KBO25 KBO2558 KBO25 KBO 2558 PP KBO25-PP KBO2558-PP KBO25-PP KBO 2558 PP AS KBO25-PP-AS KBO2558-PP-AS KBO25-PP-AS KBO 3068 KBO30 KBO3068 KBO30 KBO 3068 PP KBO30-PP KBO3068-PP KBO30-PP KBO 3068 PP AS KBO30-PP-AS KBO3068-PP-AS KBO30-PP-AS KBO 4080 KBO40 KBO4080 KBO40 KBO 4080 PP KBO40-PP KBO4080-PP KBO40-PP KBO 4080 PP AS KBO40-PP-AS KBO4080-PP-AS KBO40-PP-AS KBO 50100 KBO50 KBO50100 KBO50 KBO 50100 PP KBO50-PP KBO50100-PP KBO50-PP KBO 50100 PP AS KBO50-PP-AS KBO50100-PP-AS KBO50-PP-AS KBS 1232 KBS12 KBS1232 KBS12 KBS 1232 PP KBS12-PP KBS1232-PP KBS12-PP KBS 1232 PP AS KBS12-PP-AS KBS1232-PP-AS KBS12-PP-AS KBS 1636 KBS16 KBS1636 KBS16 KBS 1636 PP KBS16-PP KBS1636-PP KBS16-PP KBS 1636 PP AS KBS16-PP-AS KBS1636-PP-AS KBS16-PP-AS KBS 2045 KBS20 KBS2045 KBS20 KBS 2045 PP KBS20-PP KBS2045-PP KBS20-PP KBS 2045 PP AS KBS20-PP-AS KBS2045-PP-AS KBS20-PP-AS KBS 2558 KBS25 KBS2558 KBS25 KBS 2558 PP KBS25-PP KBS2558-PP KBS25-PP KBS 2558 PP AS KBS25-PP-AS KBS2558-PP-AS KBS25-PP-AS KBS 3068 KBS30 KBS3068 KBS30 KBS 3068 PP KBS30-PP KBS3068-PP KBS30-PP KBS 3068 PP AS KBS30-PP-AS KBS3068-PP-AS KBS30-PP-AS KBS 4080 KBS40 KBS4080 KBS40 KBS 4080 PP KBS40-PP KBS4080-PP KBS40-PP KBS 4080 PP AS KBS40-PP-AS KBS4080-PP-AS KBS40-PP-AS KBS 50100 KBS50 KBS50100 KBS50 KBS 50100 PP KBS50-PP KBS50100-PP KBS50-PP KBS 50100 PP AS KBS50-PP-AS KBS50100-PP-AS KBS50-PP-AS KBZ 04 PP KBZ04-PP KBZ 06 PP KBZ06-PP KBZ 08 OP KBZ08-OP KBZ 08 OP PP KBZ08-OP-PP KBZ 08 PP KBZ08-PP KBZ 10 OP KBZ10-OP KBZ 10 OP PP KBZ10-OP-PP KBZ 10 PP KBZ10-PP KBZ 12 OP KBZ12-OP KBZ 12 OP PP KBZ12-OP-PP KBZ 12 PP KBZ12-PP KBZ 16 OP KBZ16-OP KBZ 16 OP PP KBZ16-OP-PP KBZ 16 PP KBZ16-PP KBZ 20 OP KBZ20-OP KBZ 20 OP PP KBZ20-OP-PP KBZ 20 PP KBZ20-PP KBZ 24 OP KBZ24-OP KBZ 24 OP PP KBZ24-OP-PP KBZ 24 PP KBZ24-PP KBZ 32 OP KBZ32-OP KBZ 32 OP PP KBZ32-OP-PP KBZ 32 PP KBZ32-PP KGB1232 PP AS KGB12-PP-AS KGB 1636 PP AS KGB16-PP-AS KGB 2045 PP AS KGB20-PP-AS KGB 2558 PP AS KGB25-PP-AS KGB 3068 PP AS KGB30-PP-AS KGB 4080 PP AS KGB40-PP-AS KGB 50100 PP AS KGB50-PP-AS KGBA 1232 PP AS KGBA12-PP-AS KGBA 1636 PP AS KGBA16-PP-AS KGBA 2045 PP AS KGBA20-PP-AS KGBA 2558 PP AS KGBA25-PP-AS KGBA 3068 PP AS KGBA30-PP-AS KGBA 4080 PP AS KGBA40-PP-AS KGBA 50100 PP AS KGBA50-PP-AS KGBAO 1232 PP AS KGBAO12-PP-AS KGBAO 1636 PP AS KGBAO16-PP-AS KGBAO 2045 PP AS KGBAO20-PP-AS KGBAO 2558 PP AS KGBAO25-PP-AS KGBAO 3068 PP AS KGBAO30-PP-AS KGBAO 4080 PP AS KGBAO40-PP-AS KGBAO 50100 PP AS KGBAO50-PP-AS KGBAS 1232 PP AS KGBAS12-PP-AS KGBAS 1636 PP AS KGBAS16-PP-AS KGBAS 2045 PP AS KGBAS20-PP-AS KGBAS 2558 PP AS KGBAS25-PP-AS KGBAS 3068 PP AS KGBAS30-PP-AS KGBAS 4080 PP AS KGBAS40-PP-AS KGBAS 50100 PP AS KGBAS50-PP-AS KGBO 1232 PP AS KGBO12-PP-AS KGBO 1636 PP AS KGBO16-PP-AS KGBO 2045 PP AS KGBO20-PP-AS KGBO 2558 PP AS KGBO25-PP-AS KGBO 3068 PP AS KGBO30-PP-AS KGBO 4080 PP AS KGBO40-PP-AS KGBO 50100 PP AS KGBO50-PP-AS KGBS 1232 PP AS KGBS12-PP-AS KGBS 1636 PP AS KGBS16-PP-AS KGBS 2045 PP AS KGBS20-PP-AS KGBS 2558 PP AS KGBS25-PP-AS KGBS 3068 PP AS KGBS30-PP-AS KGBS 4080 PP AS KGBS40-PP-AS KGBS 50100 PP AS KGBS50-PP-AS KGEH MDKUE 15 3ZR-110/130/M8 KGEH.MDKUE15-3ZR-110/130/M8 KGEH MDKUE 15 ZR-110/130/M8 KGEH.MDKUE15-ZR-110/130/M8 KGEH MDKUE 25 ZR-110/130/M8 KGEH.MDKUE25-ZR-110/130/M8 KGEH MKUE 25 KGT-110/130/M8 KGEH.MKUE25-KGT-110/130/M8 KGEH MKUE 25 KGT-130/165/M10 KGEH.MKUE25-KGT-130/165/M10 KGEH MKUE 25 KGT-80/100/M6 KGEH.MKUE25-KGT-80/100/M6 KGEH MKUE 25 KGT-95/115/M8 KGEH.MKUE25-KGT-95/115/M8 KGEH MLF 32 ZR-110/130/M8 KGEH.MLF32-ZR-110/130/M8 KGEH MLF 32 ZR-45/70/M5 KGEH.MLF32-ZR-45/70/M5 KGEH MLF 32 ZR-80/100/M6 KGEH.MLF32-ZR-80/100/M6 KGEH MLF 32 ZR-95/115/M8 KGEH.MLF32-ZR-95/115/M8 KGEH MLF 52 ZR-110/130/M8 KGEH.MLF52-ZR-110/130/M8 KGEH MLF 52 ZR-80/100/M6 KGEH.MLF52-ZR-80/100/M6 KGEH MLFI 25 ZR-40/52/5,5 KGEH.MLFI25-ZR-40/52/5,5 KGEH MLFI 25 ZR-50/65/5,5 KGEH.MLFI25-ZR-50/65/5,5 KGEH MLFI 25 ZR-60/75/M5 KGEH.MLFI25-ZR-60/75/M5 KGHK 06 B PP AS KGHK06-B-PP-AS KGHK 08 B PP AS KGHK08-B-PP-AS KGHK 10 B PP AS KGHK10-B-PP-AS KGHK 12 B PP AS KGHK12-B-PP-AS KGHK 14 B PP AS KGHK14-B-PP-AS KGHK 16 B PP AS KGHK16-B-PP-AS KGHK 20 B PP AS KGHK20-B-PP-AS KGHK 25 B PP AS KGHK25-B-PP-AS KGHK 30 B PP AS KGHK30-B-PP-AS KGHK 40 B PP AS KGHK40-B-PP-AS KGHK 50 B PP AS KGHK50-B-PP-AS KGSC 20 PP AS KGSC20-PP-AS KGSC 25 PP AS KGSC25-PP-AS KGSC 30 PP AS KGSC30-PP-AS KGSC 40 PP AS KGSC40-PP-AS KGSC 50 PP AS KGSC50-PP-AS KGSCS 20 PP AS KGSCS20-PP-AS KGSCS 25 PP AS KGSCS25-PP-AS KGSCS 30 PP AS KGSCS30-PP-AS KGSCS 40 PP AS KGSCS40-PP-AS KGSCS 50 PP AS KGSCS50-PP-AS KGSNG 12 PP AS KGSNG12-PP-AS KGSNG 16 PP AS KGSNG16-PP-AS KGSNG 20 PP AS KGSNG20-PP-AS KGSNG 25 PP AS KGSNG25-PP-AS KGSNG 30 PP AS KGSNG30-PP-AS KGSNG 40 PP AS KGSNG40-PP-AS KGSNG 50 PP AS KGSNG50-PP-AS KGSNO 12 PP AS KGSNO12-PP-AS KGSNO 16 PP AS KGSNO16-PP-AS KGSNO 20 PP AS KGSNO20-PP-AS KGSNO 25 PP AS KGSNO25-PP-AS KGSNO 30 PP AS KGSNO30-PP-AS KGSNO 40 PP AS KGSNO40-PP-AS KGSNO 50 PP AS KGSNO50-PP-AS KGSNOS 12 PP AS KGSNOS12-PP-AS KGSNOS 16 PP AS KGSNOS16-PP-AS KGSNOS 20 PP AS KGSNOS20-PP-AS KGSNOS 25 PP AS KGSNOS25-PP-AS KGSNOS 30 PP AS KGSNOS30-PP-AS KGSNOS 40 PP AS KGSNOS40-PP-AS KGSNOS 50 PP AS KGSNOS50-PP-AS KGSNS 12 PP AS KGSNS12-PP-AS KGSNS 16 PP AS KGSNS16-PP-AS KGSNS 20 PP AS KGSNS20-PP-AS KGSNS 25 PP AS KGSNS25-PP-AS KGSNS 30 PP AS KGSNS30-PP-AS KGSNS 40 PP AS KGSNS40-PP-AS KGSNS 50 PP AS KGSNS50-PP-AS KGX 08 PP KGX08-PP KGX 10 PP KGX10-PP KGX 12 PP KGX12-PP KGX 16 PP KGX16-PP KGX 20 PP KGX20-PP KGX 24 PP KGX24-PP KGX 32 PP KGX32-PP KGXO 08 PP KGXO08-PP KGXO 10 PP KGXO10-PP KGXO 12 PP KGXO12-PP KGXO 16 PP KGXO16-PP KGXO 20 PP KGXO20-PP KGXO 24 PP KGXO24-PP KGXO 32 PP KGXO32-PP KH 0622 KH06 KH0622 KH06 KH 0622 PP KH06-PP KH0622-PP KH06-PP KH 0824 KH08 KH0824 KH08 KH 0824 PP KH08-PP KH0824-PP KH08-PP KH 1026 KH10 KH1026 KH10 KH 1026 PP KH10-PP KH1026-PP KH10-PP KH 1228 KH12 KH1228 KH12 KH 1228 PP KH12-PP KH1228-PP KH12-PP KH 1428 KH14 KH1428 KH14 KH 1428 PP KH14-PP KH1428-PP KH14-PP KH 1630 KH16 KH1630 KH16 KH 1630 PP KH16-PP KH1630-PP KH16-PP KH 2030 KH20 KH2030 KH20 KH 2030 PP KH20-PP KH2030-PP KH20-PP KH 2540 KH25 KH2540 KH25 KH 2540 PP KH25-PP KH2540-PP KH25-PP KH 3050 KH30 KH3050 KH30 KH 3050 PP KH30-PP KH3050-PP KH30-PP KH 4060 KH40 KH4060 KH40 KH 4060 PP KH40-PP KH4060-PP KH40-PP KH 5070 KH50 KH5070 KH50 KH 5070 PP KH50-PP KH5070-PP KH50-PP KH913849.H913810 KH913849-H913810 KHM215249.HM215210 KHM215249-HM215210 KHM218248.HM218210 KHM218248-HM218210 KHM518445.HM518410 KHM518445-HM518410 KHM804840.HM804810 KHM804840-HM804810 KHM88542.HM88510 KHM88542-HM88510 KHM88649.HM88610 KHM88649-HM88610 KHM911245.HM911210 KHM911245-HM911210 KL44643.L44610 KL44643-L44610 KL44649.L44610 KL44649-L44610

INA直线轴承KB12-PP-AS轴承我司目前有部分库存，您可致电我司咨询销售人员关于轴承KB12-PP-AS的图纸、轴承KB12-PP-AS价格或同型号其他品牌替换等资料！我司与INA厂家常年批量订购KB12-PP-AS直线轴承，以保证KB12-PP-AS轴承质量正宗，价格最优。订购原装INA KB12-PP-AS轴承请拨打：0532-83735255、13061287818
