FAG轴承MS9

电询库存情况

产品描述

品牌	FAG	型号	英制深沟球轴承MS9	加工定制	是
是否标准件	标准件	样品或现货	现货	是否进口	进口
类型	钢球	用途	深沟球轴承	材质	碳钢
尺寸	英制深沟球轴承MS9

进口FAG英制深沟球轴承MS9内径22.225mm外径57.15mm厚度17.462mm
进口FAG英制深沟球轴承MS9内径22.225mm外径57.15mm厚度17.462mm

Bearing No	Dimesions(inch)			Dimensions(mm)			Approx. weight kg.	Interchange
Bearing No	d	D	B	d	D	B	Approx. weight kg.	SKF	FAG
MJ 1/2	1/2	1.5/8	5/8	12.700	41.275	15.88	0.10	RMS 4	MS 5
MJ 5/8	5/8	1.13/16	5/8	15.875	46.038	15.88	0.12	RMS 5	MS 7
MJ 3/4	3/4	2	11/16	19.050	50.800	17.46	0.16	RMS 6	MS 8
MJ 7/8	7/8	2.1/4	11/16	22.225	57.150	17.46	0.20	RMS 7	MS 9
MJ 1	1	2.1/2	3/4	25.400	63.500	19.05	0.26	RMS 8	MS10
MJ 1.1/8	1.1/8	2.13/16	13/16	28.575	71.438	20.64	0.35	RMS 9	MS 11
MJ1.1/4	1.1/4	3.1/8	7/8	31.750	79.375	22.23	0.48	RMS 10	MS 12
MJ 1.3/8	1.3/8	3.1/2	7/8	34.925	88.900	22.23	0.61	RMS 11	MS 12.1/2
MJ 1.1/2	1.1/2	3.3/4	15/16	38.100	95.250	23.81	0.75	RMS 12	MS 13
MJ1.5/8	1.5/8	4	15/16	41.275	101.600	23.81	0.86	RMS 13	MS 13.1/2
MJ1.3/4	1.3/4	4.1/4	1.1/16	44.450	107.950	26.99	1.06	RMS 14	MS 14
MJ 1.7/8	1.7/8	4.1/2	1.1/16	47.625	140.300	26.99	1.22	RMS 15	MS 14.1/2
MJ 2	2	4.1/2	1.1/16	50.800	114.300	26.99	1.17	RMS 16	MS 15
MJ 2.1/4	2.1/4	5	1.1/4	57.150	127.000	31.75	1.60	RMS 18	MS 16
MJ 2.1/2	2.1/2	5.1/2	1.1/4	63.500	139.700	31.75	2.04	RMS 20	MS 17
MJ 2.3/4	2.3/4	6.1/4	1.3/8	69.850	158.750	34.93	2.89	RMS 22	MS 18
MJ 3	3	7	1.9/16	76.200	177.800	39.69	4.25	RMS 24	MS 19
MJ 3.1/4	3.1/4	7.1/2	1.9/16	82.550	190.500	39.69	4.99	RMS 26	MS 19.1/2
MJ 3.1/2	3.1/2	8.1/8	1.3/4	88.900	206.375	44.45	6.53	RMS 28	MS 20
MJ 3.3/4	3.3/4	8.1/4	1.3/4	95.250	209.550	44.45	6.53	RMS 30	MS 20.1/2
MJ 4	4	8.1/2	1.3/4	101.600	215.900	44.45	6.71	RMS 32	MS 21
MJ 4.1/4	4.1/4	8.3/4	1.3/4	107.950	222.250	44.45	8.16	RMS 34	MS 21.1/2
MJ 4.1/2	4.1/2	9.3/8	2	114.300	238.125	50.80	10.70	RMS 36	MS 22
MJ 4.3/4	4.3/4	10	2	120.650	254.000	50.80	13.20	RMS 38	MS 22.1/2
MJ 5	5	10	2	127.000	254.000	50.80	12.20	RMS 40	MS 23
MJ 5.1/2	5.1/2	11	2	139.700	279.400	50.80	14.90	RMS 44	MS 23.1/2
MJ 6	6	12	2.1/4	152.400	304.800	57.15	19.50	RMS 48	MS 24
MJ 6.1/2	6.1/2	13	2.1/2	165.100	330.200	63.50	26.50	RMS 52	MS 24.1/2
MJ 7	7	13.1/2	2.1/2	177.800	342.900	63.50	27.50	RMS 56	MS 25
MJ 7.1/2	7.1/2	14.1/2	2.3/4	190.500	368.300	69.85	35.40	RMS 60	MS 25.1/2
MJ 8	8	15	2.3/4	203.200	381.000	69.85	36.50	RMS 64	MS 26
MJ 8.1/2	8.1/2	16	3	215.900	406.400	76.20	47.20	RMS 68	MS 26.1/2

轴承型号展示

经销品牌

需要帮助？

FAG轴承MS9

产品描述

进口FAG英制深沟球轴承MS9内径22.225mm外径57.15mm厚度17.462mm
