FAG轴承2208-K-2RS-TVH-C3

FAG轴承2208-K-2RS-TVH-C3

  • 型号：
  • 2208-K-2RS-TVH-C3
  • 品牌：
  • FAG轴承
  • 系列：
  • 调心球轴承
  • 内径d：
  • 40 mm
  • 外径D：
  • 80 mm
  • 厚度B：
  • 23 mm
FAG轴承2208-K-2RS-TVH-C3参数
品牌 FAG 型号 调心球轴承2208K.2RS.TV.C3 加工定制 是
是否标准件 标准件 样品或现货 现货 是否进口 进口
类型 钢球 用途 调心球轴承 材质 碳钢
尺寸 调心球轴承 2208-K-2RS-TVH-C3






FAG自调心球轴承2208-K-2RS-TVH-C3


根据 DIN 630 标准的主要尺寸，锥孔，锥度 1:12，两侧唇密封

 FAG调心球轴承2208K-2RS-TV-C3

FAG调心球轴承2208K-2RS-TV-C3 (2)

FAG调心球轴承2208K-2RS-TV-C3 (3)



自调心球轴承 2208-K-2RS-TVH-C3, 根据 DIN 630 标准的主要尺寸，锥孔，锥度 1:12，两侧唇密封
径向载荷单向轴向载荷双向轴向载荷静转角误差和不对中动转角误差和不对中双侧密封终生润滑，免维护脂润滑
自调心球轴承 2208-K-2RS-TVH-C3, 根据 DIN 630 标准的主要尺寸，锥孔，锥度 1:12，两侧唇密封


d 40 mm

D 80 mm

B 23 mm


D2 71,1 mm

Da max 73 mm

da min 47 mm

ra max 1 mm

rmin 1,1 mm


m 0,517 kg
  质量
Cr 19400 N
  基本额定动载荷，径向
e 0,22

Y1 2,9

Y2 4,49

C0r 6500 N
  基本额定静载荷，径向
Y0 3,04

nG 6300 1/min
  极限转速
nB 0 1/min
  参考速度
Cur 400 N
  疲劳极限载荷，径向

Brand:FAG

135TV                                       126TV 127TV                                 129TV

108TV

 108-TVH
11204TV 11204-TVH
11205TV 11205-TVH
11206TV 11206-TVH
11207TV 11207-TVH
11208TV 11208-TVH
11209TV 11209-TVH
11210TV 11210-TVH
11211TV 11211-TVH
11212TV 11212-TVH
1200TV 1200-TVH
1201TV 1201-TVH
1202TV 1202-TVH
1203TV 1203-TVH
1204K.TV.C3 1204-K-TVH-C3
1204K.TV.C3 1204-K-TVH-C3 + H204
1204TV 1204-TVH
1205K.TV.C3 1205-K-TVH-C3
1205K.TV.C3 1205-K-TVH-C3 + H205
1205TV 1205-TVH
1206K.TV.C3 1206-K-TVH-C3
1206K.TV.C3 1206-K-TVH-C3 + H206
1206TV 1206-TVH
1207K.TV.C3 1207-K-TVH-C3
1207K.TV.C3 1207-K-TVH-C3 + H207
1207TV 1207-TVH
1208K.TV.C3 1208-K-TVH-C3
1208K.TV.C3 1208-K-TVH-C3 + H208
1208TV 1208-TVH
1209K.TV.C3 1209-K-TVH-C3
1209K.TV.C3 1209-K-TVH-C3 + H209
1209TV 1209-TVH
1210K.TV.C3 1210-K-TVH-C3
1210K.TV.C3 1210-K-TVH-C3 + H210
1210TV 1210-TVH
1211K.TV.C3 1211-K-TVH-C3
1211K.TV.C3 1211-K-TVH-C3 + H211
1211TV 1211-TVH
1212K.TV.C3 1212-K-TVH-C3
1212K.TV.C3 1212-K-TVH-C3 + H212
1212TV 1212-TVH
1213K.TV.C3 1213-K-TVH-C3
1213K.TV.C3 1213-K-TVH-C3 + H213
1213TV 1213-TVH
1214K.TV.C3 1214-K-TVH-C3
1214K.TV.C3 1214-K-TVH-C3 + H214
1214TV 1214-TVH
1215K.TV.C3 1215-K-TVH-C3
1215K.TV.C3 1215-K-TVH-C3 + H215
1215TV 1215-TVH
1216K.TV.C3 1216-K-TVH-C3
1216K.TV.C3 1216-K-TVH-C3 + H216
1216TV 1216-TVH
1217K.TV.C3 1217-K-TVH-C3
1217K.TV.C3 1217-K-TVH-C3 + H217
1217TV 1217-TVH
1218K.TV.C3 1218-K-TVH-C3
1218K.TV.C3 1218-K-TVH-C3 + H218
1218TV 1218-TVH
1219K.M.C3 1219-K-M-C3
1219K.M.C3 1219-K-M-C3 + H219
1219M 1219-M
1220K.M.C3 1220-K-M-C3
1220K.M.C3 1220-K-M-C3 + H220
1220M 1220-M
1221M 1221-M
1222K.M.C3 1222-K-M-C3
1222K.M.C3 1222-K-M-C3 + H222
1222M 1222-M
1224M 1224-M
1226M 1226-M
1228M 1228-M
1230M 1230-M
126TV 126-TVH
127TV 127-TVH
129TV 129-TVH
1303TV 1303-TVH
1304TV 1304-TVH
1305K.TV.C3 1305-K-TVH-C3
1305K.TV.C3 1305-K-TVH-C3 + H305
1305TV 1305-TVH
1306K.TV.C3 1306-K-TVH-C3
1306K.TV.C3 1306-K-TVH-C3 + H306
1306TV 1306-TVH
1307K.TV.C3 1307-K-TVH-C3
1307K.TV.C3 1307-K-TVH-C3 + H307
1307TV 1307-TVH
1308K.TV.C3 1308-K-TVH-C3
1308K.TV.C3 1308-K-TVH-C3 + H308
1308TV 1308-TVH
1309K.TV.C3 1309-K-TVH-C3
1309K.TV.C3 1309-K-TVH-C3 + H309
1309TV 1309-TVH
1310K.TV.C3 1310-K-TVH-C3
1310K.TV.C3 1310-K-TVH-C3 + H310
1310TV 1310-TVH
1311K.TV.C3 1311-K-TVH-C3
1311K.TV.C3 1311-K-TVH-C3 + H311
1311TV 1311-TVH
1312K.TV.C3 1312-K-TVH-C3
1312K.TV.C3 1312-K-TVH-C3 + H312
1312TV 1312-TVH
1313K.TV.C3 1313-K-TVH-C3
1313K.TV.C3 1313-K-TVH-C3 + H313
1313TV 1313-TVH
1314M 1314-M
1315K.M.C3 1315-K-M-C3
1315K.M.C3 1315-K-M-C3 + H315
1315M 1315-M
1316K.M.C3 1316-K-M-C3
1316K.M.C3 1316-K-M-C3 + H316
1316M 1316-M
1317K.M.C3 1317-K-M-C3
1317K.M.C3 1317-K-M-C3 + H317
1317M 1317-M
1318K.M.C3 1318-K-M-C3
1318K.M.C3 1318-K-M-C3 + H318
1318M 1318-M
1319K.M.C3 1319-K-M-C3
1319K.M.C3 1319-K-M-C3 + H319
1319M 1319-M
1320K.M.C3 1320-K-M-C3
1320K.M.C3 1320-K-M-C3 + H320
1320M 1320-M
1321M 1321-M
1322K.M.C3 1322-K-M-C3
1322K.M.C3 1322-K-M-C3 + H322
1322M 1322-M
135TV 135-TVH
16056M 16056-M
16060M 16060-M
16064M 16064-M
16068M 16068-M
16072M 16072-M
16076M 16076-M
2200.2RS.TV 2200-2RS-TVH
2200TV 2200-TVH
2201.2RS.TV 2201-2RS-TVH
2201TV 2201-TVH
2202.2RS.TV 2202-2RS-TVH
2202TV 2202-TVH
2203.2RS.TV 2203-2RS-TVH
2203TV 2203-TVH
2204.2RS.TV 2204-2RS-TVH
2204TV 2204-TVH
2205.2RS.TV 2205-2RS-TVH
2205K.2RS.TV.C3 2205-K-2RS-TVH-C3
2205K.2RS.TV.C3 2205-K-2RS-TVH-C3 + H305
2205K.TV.C3 2205-K-TVH-C3
2205K.TV.C3 2205-K-TVH-C3 + H305
2205TV 2205-TVH
2206.2RS.TV 2206-2RS-TVH
2206K.2RS.TV.C3 2206-K-2RS-TVH-C3
2206K.2RS.TV.C3 2206-K-2RS-TVH-C3 + H306
2206K.TV.C3 2206-K-TVH-C3
2206K.TV.C3 2206-K-TVH-C3 + H306
2206TV 2206-TVH
2207.2RS.TV 2207-2RS-TVH
2207K.2RS.TV.C3 2207-K-2RS-TVH-C3
2207K.2RS.TV.C3 2207-K-2RS-TVH-C3 + H307
2207K.TV.C3 2207-K-TVH-C3
2207K.TV.C3 2207-K-TVH-C3 + H307
2207TV 2207-TVH
2208.2RS.TV 2208-2RS-TVH
2208K.2RS.TV.C3 2208-K-2RS-TVH-C3
2208K.2RS.TV.C3 2208-K-2RS-TVH-C3 + H308
2208K.TV.C3 2208-K-TVH-C3
2208K.TV.C3 2208-K-TVH-C3 + H308
2208TV 2208-TVH
2209.2RS.TV 2209-2RS-TVH
2209K.2RS.TV.C3 2209-K-2RS-TVH-C3
2209K.2RS.TV.C3 2209-K-2RS-TVH-C3 + H309
2209K.TV.C3 2209-K-TVH-C3
2209K.TV.C3 2209-K-TVH-C3 + H309
2209TV 2209-TVH
2210.2RS.TV 2210-2RS-TVH
2210K.2RS.TV.C3 2210-K-2RS-TVH-C3
2210K.2RS.TV.C3 2210-K-2RS-TVH-C3 + H310
2210K.TV.C3 2210-K-TVH-C3
2210K.TV.C3 2210-K-TVH-C3 + H310
2210TV 2210-TVH
2211.2RS.TV 2211-2RS-TVH
2211K.2RS.TV.C3 2211-K-2RS-TVH-C3
2211K.2RS.TV.C3 2211-K-2RS-TVH-C3 + H311
2211K.TV.C3 2211-K-TVH-C3
2211K.TV.C3 2211-K-TVH-C3 + H311
2211TV 2211-TVH
2212.2RS.TV 2212-2RS-TVH
2212K.2RS.TV.C3 2212-K-2RS-TVH-C3
2212K.2RS.TV.C3 2212-K-2RS-TVH-C3 + H312
2212K.TV.C3 2212-K-TVH-C3
2212K.TV.C3 2212-K-TVH-C3 + H312
2212TV 2212-TVH
2213.2RS.TV 2213-2RS-TVH
2213K.2RS.TV.C3 2213-K-2RS-TVH-C3
2213K.2RS.TV.C3 2213-K-2RS-TVH-C3 + H313
2213K.TV.C3 2213-K-TVH-C3
2213K.TV.C3 2213-K-TVH-C3 + H313
2213TV 2213-TVH
2214.2RS.TV 2214-2RS-TVH
2214M 2214-M
2215K.TV.C3 2215-K-TVH-C3
2215K.TV.C3 2215-K-TVH-C3 + H315
2215TV 2215-TVH
2216K.TV.C3 2216-K-TVH-C3
2216K.TV.C3 2216-K-TVH-C3 + H316
2216TV 2216-TVH
2217K.M.C3 2217-K-M-C3
2217K.M.C3 2217-K-M-C3 + H317
2217M 2217-M
2218K.TV.C3 2218-K-TVH-C3
2218K.TV.C3 2218-K-TVH-C3 + H318
2218TV 2218-TVH
2219K.M.C3 2219-K-M-C3
2219K.M.C3 2219-K-M-C3 + H319
2219M 2219-M

FAG调心球轴承2208-K-2RS-TVH-C3轴承我司目前有部分库存，您可致电我司咨询销售人员关于轴承2208-K-2RS-TVH-C3的图纸、轴承2208-K-2RS-TVH-C3价格或同型号其他品牌替换等资料！我司与FAG厂家常年批量订购2208-K-2RS-TVH-C3调心球轴承，以保证2208-K-2RS-TVH-C3轴承质量正宗，价格最优。订购原装FAG 2208-K-2RS-TVH-C3轴承请拨打：0532-83735255、13061287818
热销轴承型号：上一篇：KOYO轴承16012 SKF 22212CC/W33轴承 FAG推力角接触球轴承 7603040-TV NACHI深沟球轴承51101G NSK 6014N轴承 NSK 40BNR10XTDUELP4高转速 精密 SKF 23132-2CS轴承 TIMKEN HM807046/HM807010-B轴承 KOYO R18/17轴承 NSK HR32320J轴承 下一篇：NSK轴承35TAC72BDBC10PN7A
FAG轴承2208-K-2RS-TVH-C3轴承图纸
