外形尺寸（mm） |
额定动负荷 |
额定静负荷 |
轴承代号 |
备注 |
|||||
|
d |
D |
B |
Df |
Bf |
rsmin |
||||
|
1.191 |
3.967 |
1.59 |
0.1 |
68.26 |
21.26 |
R0 |
|||
|
2.38 |
4.762 |
2.38 |
0.08 |
176,84 |
55.24 |
R133ZZ |
|||
|
2.381 |
4.763 |
1.588 |
5.944 |
0.457 |
0.08 |
99.09 |
34.69 |
FR133/WB |
宽内圈2.381 |
|
2.381 |
7.938 |
3.571 |
0.15 |
194.97 |
78.45 |
R1-5ZZ |
|||
|
3.175 |
6.35 |
2.38 |
0.1 |
194.84 |
77.88 |
R144 |
|||
|
3.175 |
6.35 |
2.38 |
0.1 |
162.73 |
58.22 |
R144/YB2 |
|||
|
3.175 |
6.35 |
2.38 |
0.1 |
194.84 |
77.88 |
R144ZY |
|||
|
3.175 |
6.35 |
2.381 |
7.518 |
0.584 |
0.08 |
268.75 |
130.21 |
FR144/WB/V |
宽内圈3.175 |
|
3.175 |
6.35 |
2.78 |
0.1 |
194.84 |
77.88 |
R144ZZ |
|||
|
3.175 |
6.35 |
2.78 |
0.1 |
194.84 |
77.88 |
R144Z |
|||
|
3.175 |
6.35 |
2.78 |
7.52 |
0.78 |
0.1 |
194.84 |
77.88 |
FR144ZZ |
|
|
3.175 |
7.938 |
2.778 |
9.119 |
0.584 |
0.1 |
290.91 |
110.75 |
FR2-5/WB |
宽内圈3.572 |
|
3.175 |
7.938 |
2.78 |
0.1 |
233.09 |
89.67 |
R2-5 |
|||
|
3.175 |
7.938 |
3.57 |
0.08 |
233.09 |
89.67 |
R2-5ZZ |
|||
|
3.175 |
7.938 |
3.57 |
0.15 |
290.30 |
111.03 |
R2-5ZZ/YA |
|||
|
3.175 |
7.938 |
3.57 |
0.08 |
233.09 |
89.67 |
R2-5HH |
|||
|
3.175 |
7.938 |
3.57 |
9.12 |
0.79 |
0.08 |
233.09 |
89.67 |
FR2-5ZZ |
|
|
3.175 |
9.525 |
3.969 |
0.15 |
309.59 |
121.19 |
R2/WB |
宽内圈4.763 |
||
|
3.175 |
9.525 |
3.97 |
0.15 |
362.22 |
121.51 |
R2ZZ |
|||
|
3.175 |
9.525 |
3.97 |
0.15 |
366.29 |
149.61 |
R2HH |
|||
|
3.175 |
9.525 |
3.97 |
0.15 |
366.29 |
149.61 |
R2-HH/YA |
|||
|
3.175 |
9.525 |
3.97 |
0.15 |
362.22 |
121.51 |
R2-2RS |
|||
|
3.175 |
9.525 |
3.97 |
0.15 |
366.29 |
149.61 |
R2-F |
|||
|
3.175 |
9.525 |
3.97 |
0.15 |
362.22 |
121.51 |
R2ZZEE |
|||
|
3.175 |
10.414 |
2.779 |
0.1 |
463.98 |
175.22 |
R174-2Z |
|||
|
3.175 |
12.7 |
4.37 |
0.15 |
366.29 |
149.61 |
R2AZZ |
|||
|
3.969 |
7.938 |
2.779 |
9.119 |
0.584 |
0.08 |
243.46 |
99.35 |
FR155/WB |
|
|
4.763 |
7.938 |
3.175 |
0.08 |
208.44 |
90.20 |
R156ZZ |
|||
|
4.763 |
7.938 |
3.175 |
9.12 |
0.914 |
0.08 |
208.44 |
90.20 |
FR156ZZ |
|
|
4.763 |
9.525 |
3.175 |
0.1 |
404.22 |
173.22 |
R166 |
|||
|
4.763 |
9.525 |
3.175 |
0.1 |
692.98 |
264.37 |
R166ZZ |
|||
|
4.763 |
9.525 |
3.175 |
0.1 |
692.98 |
264.37 |
RW166ZZ |
|||
|
4.763 |
9.525 |
3.175 |
10.719 |
0.787 |
0.1 |
692.98 |
264.37 |
FR166-2Z |
|
|
4.763 |
9.525 |
3.18 |
10.72 |
0.91 |
0.08 |
187.15 |
83.74 |
FRW168ZZ |
|
|
4.763 |
12.7 |
3.96 |
0.15 |
1290.83 |
487.43 |
R3 |
|||
|
4.763 |
12.7 |
4.98 |
0.15 |
1286.55 |
485.13 |
R3ZZWB |
|||
|
4.763 |
12.7 |
4.98 |
0.15 |
1156.81 |
408.01 |
R3-2Z TN1/YA |
|||
|
4.763 |
12.7 |
4.98 |
0.15 |
1164.76 |
417.80 |
R3ZZ |
|||
|
4.763 |
12.7 |
4.98 |
0.15 |
1290.83 |
487.43 |
R3HH |
|||
|
4.763 |
12.7 |
4.98 |
0.15 |
1290.83 |
487.43 |
R3-2RS |
|||
|
4.763 |
12.7 |
4.98 |
0.15 |
1290.83 |
487.43 |
R3-2RSA |
|||
|
4.763 |
12.7 |
4.98 |
14.35 |
1.06 |
0.15 |
1290.83 |
487.43 |
FR3ZZ |
|
|
6.35 |
9.525 |
3.18 |
0.08 |
209.19 |
98.97 |
R168ZZ |
|||
|
6.35 |
9.525 |
3.18 |
10.72 |
0.91 |
0.08 |
187.15 |
83.74 |
FR168ZZ |
|
|
6.35 |
12.7 |
3.175 |
13.894 |
0.584 |
0.15 |
457.45 |
220.82 |
FR188 |
|
|
6.35 |
12.7 |
3.18 |
0.15 |
625.74 |
283.27 |
R188 |
|||
|
6.35 |
12.7 |
4.76 |
0.15 |
625.74 |
283.27 |
R188ZZ |
|||
|
6.35 |
12.7 |
4.76 |
0.15 |
625.74 |
283.27 |
R188Z |
|||
|
6.35 |
12.7 |
4.76 |
0.15 |
625.74 |
283.27 |
R188HH |
|||
|
6.35 |
12.7 |
4.76 |
13.89 |
1.14 |
0.15 |
625.74 |
283.27 |
FR188ZZ |
|
|
6.35 |
12.7 |
4.76 |
13.89 |
1.14 |
0.15 |
625.74 |
283.27 |
FR188-2ZWB |
|
|
6.35 |
15.875 |
4.978 |
0.2 |
1452.09 |
603.46 |
R4/YA |
|||
|
6.35 |
15.875 |
4.98 |
0.3 |
1430.33 |
584.75 |
R4-ZZ |
|||
|
6.35 |
15.875 |
4.98 |
0.15 |
1430.33 |
584.75 |
R4 |
|||
|
6.35 |
15.875 |
4.98 |
0.2 |
1430.33 |
584.75 |
R4HH |
|||
|
6.35 |
15.875 |
4.98 |
0.3 |
1452.09 |
603.46 |
R4HH/YA |
|||
|
6.35 |
15.875 |
4.98 |
0.3 |
1430.33 |
584.75 |
R4-2RS |
|||
|
6.35 |
15.875 |
4.98 |
0.3 |
1430.33 |
584.75 |
R4-2RS/YA |
|||
|
6.35 |
15.875 |
4.98 |
0.3 |
1430.33 |
584.75 |
R4-2RZ |
|||
|
6.35 |
15.875 |
4.98 |
17.526 |
1.07 |
0.2 |
1430.33 |
584.75 |
FR4ZZ |
|
|
6.35 |
15.875 |
4.98 |
17.526 |
1.07 |
0.2 |
1430.33 |
584.75 |
FR4 |
|
|
6.35 |
15.875 |
4.98 |
17.526 |
1.07 |
0.2 |
1430.33 |
584.75 |
FR4-2RS |
|
|
6.35 |
15.875 |
4.98 |
17.526 |
1.07 |
0.2 |
1430.33 |
584.75 |
FR4-HH |
|
|
6.35 |
15.875 |
4.98 |
17.526 |
1.07 |
0.2 |
1430.33 |
584.75 |
FR4ZZEE |
|
|
6.35 |
15.875 |
4.98 |
18.31 |
1.78 |
0.2 |
1435.09 |
587.53 |
90723-88 |
|
|
6.35 |
17.462 |
6.35 |
0.2 |
1932.50 |
720.47 |
1602ZZ |
|||
|
6.35 |
17.462 |
6.35 |
0.2 |
1932.50 |
720.47 |
1602HH |
|||
|
6.35 |
17.462 |
6.35 |
0.15 |
1932.50 |
720.47 |
1602-2ZN |
|||
|
6.35 |
17.462 |
7.92 |
0.3 |
2171.10 |
874.17 |
R4-112RS |
|||
|
6.35 |
17.462 |
7.923 |
0.2 |
2731.32 |
1020.45 |
1602-2RS |
|||
